Curve - Changer Top White
Assembly Instructions
Dimensions
Width - 76cm
Depth - 41,5cm
Height - 14cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800
- Please keep for future reference
377/3585
Issue 1 - 01/03/13
Advertisement
Related Manuals for Argos Curve 377/3585
Summary of Contents for Argos Curve 377/3585
- Page 1 Curve - Changer Top White Assembly Instructions - Please keep for future reference 377/3585 Dimensions Width - 76cm Depth - 41,5cm Height - 14cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 01/03/13...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly . Check you have all the . We do not This product contain components and tools listed on Natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below Base panel ( 73 x 39.5cm Back panel ( 73 x 13cm Right side panel ( 41,8 x 11cm Left side panel ( 41,8 x 11cm...
- Page 4 If you have damaged or missing components, Components - Fittings call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Assembly Instructions Step 1 Insert wooden dowels into back panel shown. Step 2 Fix right side panel base panel using bolts and allen key Make sure countersunk hole is facing up!
- Page 6 Assembly Instructions Step 3 Attach back panel to the right side panel using bolt and allen key The warning label should face inwards. Step 4 Attach left side panel using bolts and allen as shown.
- Page 7 Assembly Instructions Step 5 Remove wall strap from the chest of drawers. Position changer unit on top of the chest and fix it with bolt and allen Fix wall strap to the changer unit as shown. It is essential that this product is fixed to the wall using wall strap supplied with chest of drawers.
-
