Chicago Dining Set - Bench
Assembly Instructions
404/4952
- Please keep for future reference
Dimensions
Length - 95cm
Width - 30cm
Height - 45cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
Issue 1 - 28/04/15
Advertisement
Related Manuals for Argos Chicago Dining Set Bench
Summary of Contents for Argos Chicago Dining Set Bench
- Page 1 Length - 95cm Width - 30cm Height - 45cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 640 0800 Issue 1 - 28/04/15...
-
Page 2: Handy Hints
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • We do not components and tools listed on or put weight on the product, this recommend the the following pages. -
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: Argos = 0345 640 0800 Please check you have all the parts listed below Seat Short stretcher x 2 (7.5 x 30 x 95cm) (2 x 5.5 x 20.5cm) - Page 4 Assembly Instructions Step 1 Attaching left legs and short stretchers Insert the short stretchers into holes on left legs as shown. Then fix through holes using screws Tighten screws using a crosshead screwdriver. Step 2 Attaching right legs Insert the short stretchers into holes on right legs...
- Page 5 Assembly Instructions Step 3 Attaching long stretcher Attach the long stretcher to the legs by inserting the dowels on the long stretcher into holes on the short Position holes up stretcher Step 4 Attaching seat Position the seat face down on a flat protected surface.
- Page 6 . Tighten screws using a crosshead screwdriver. Carefully turn over the unit. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 640 0800...
