Cucina Light Oak - Pair of Chairs
Assembly Instructions
Dimensions
Width - 44cm
Depth - 51.6cm
Height - 92cm
Important
- Please read these instructions fully before starting assembly.
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
IW-17-8025-112-0
- Please keep for future reference
603/0689
Issue 1 - 12/06/10
Advertisement
Related Manuals for Argos Cucina Light Oak Pair of Chairs
Summary of Contents for Argos Cucina Light Oak Pair of Chairs
- Page 1 Cucina Light Oak - Pair of Chairs Assembly Instructions 603/0689 - Please keep for future reference Dimensions Width - 44cm Depth - 51.6cm Height - 92cm Important - Please read these instructions fully before starting assembly. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 IW-17-8025-112-0 Issue 1 - 12/06/10...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly. • Check you have all the • Do not stand or put weight on • We do not the product, this could cause recommend the components and tools listed on page 2.
- Page 3 If you have damaged or missing components, Components - Panels call the Customer Helpline: 08456 400800 Please check you have all the panels listed below. 3 Right apron 2 Left apron (37 x 5.5cm) (37 x 5.5cm) 4 Left stretcher 5 Right stretcher (38.1 x 2.4cm) (38.1 x 2.4cm)
- Page 4 Assembly Instructions Step 1 Attaching aprons and stretchers. Position left apron 2 , and right apron 3 onto back leg frame 1 Insert 4 hex head bolts into left apron 2 and Slot right apron 3 . Use allen key to turn hex head bolts clockwise to fix.
- Page 5 Assembly Instructions Step 2 Attaching front leg frame. Position front leg frame 6 onto left apron 2 , right apron 3 and both left & right stretchers 4 & 5 . Ensure the dowels are aligned correctly with mating front leg frame to avoid damage.
- Page 6 Assembly Instructions Step 3 Fixing front leg frame. Carefully stand chair upright. Insert 2 hex head bolt into the predrilled holes on left apron 2 and right apron 3 . Use allen key to turn hex head bolts clockwise to fix. Step 4 Fixing stretchers.
- Page 7 Assembly Instructions Step 6 Fixing seat pad. Insert 2 seat brackets into the slots on left apron 2 and right apron Note: Align holes on seat brackets with holes on seat pad 7 . Insert 2 hex head bolts into the holes of seat brackets and the holes of mating seat pad...
