MADRID SPRING CUSHION CHAIR
Assembly Instructions - Please keep for future reference
Dimensions
Width - 61.5cm
Depth - 73.5cm
Height - 91.5cm
Important - Read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456400800
For further assistance please visit http://www.argos-support.co.uk/
6187862
Issue 1 - 24/10/16
