- Page 1 • Toll Free: 888-883-5144 Hydraulic ground rod driver Operator’s Instructions LGRD-RV 16 LGRD-RV 25 2006-03 © Copyright 2005 No 3392 5007 01a ATLAS COPCO CONSTRUCTION TOOLS AB STOCKHOLM • SWEDEN www.atlascopco.com...
-
Page 2: Safety Regulations
• For reasons of product safety, the product must not be modified. • Use approved personal protective equipment. • Use Atlas Copco Genuine Parts only. • Replace damaged or worn plates. • Only trained personnel may work on the product. -
Page 3: Personal Protective Equipment
www.CrowderSupply.com • Toll Free: 888-883-5144 English Personal protective equipment Working zone WARNING WARNING Long-term exposure to loud noise can cause Do not use the hydraulic ground rod driver permanent damage hearing in an explosive environment. protectors are not used. Make sure that no other personnel trespass into the working zone. -
Page 4: Hot Surfaces
www.CrowderSupply.com • Toll Free: 888-883-5144 English WARNING Hot surfaces DO NOT operate the ground rod driver at hydraulic oil temperatures higher than 60° C (140° F). Higher temperatures will transmitted to the ground rod driver controls and may burn. WARNING Connecting/disconnecting the ground rod driver Accumulator... - Page 5 www.CrowderSupply.com • Toll Free: 888-883-5144 The LGRD requires an oil flow of 25-30 l.p.m. and then works at a pressure of 105-125 bar. Disconnecting the ground rod driver WARNING WARNING Please read the maintenance Hydraulic oil at pressure can injure you. Follow instructions carefully before using the the instructions below for connecting the hoses.
- Page 6 www.CrowderSupply.com • Toll Free: 888-883-5144 Choice of ground rod driver The A/C range of the LGRD is a heavy-duty, hydraulically powered reciprocating tools designed for driving ground rods of various lengths. The high power-to-weight ratio and low vibration reduce operator fatigue and increase productivity.
- Page 7 • Toll Free: 888-883-5144 Technical Data Atlas Copco LGRD LGRD w/remote valve: Weight without hoses, remote valve and adaptor....20.5 kg LGRD w/remote valve: Service weight incl. tail-hose, valve and adaptor ....24.0 kg Oil flow range ....................25-30 l.p.m.
-
Page 8: Service Schedules
Waste hydraulic oil shall be handled in such as way as to cause no environmental impact. Recommended hydraulic oil In order to protect the environment Atlas Copco recommends the use of biologically degradable hydraulic oil. Viscosity 20 –... -
Page 9: Fault Finding
www.CrowderSupply.com • Toll Free: 888-883-5144 Fault finding English WARNING Maintenance must be done only by suitable qualified and competent persons. Symptom Possible fault Remedy Ground rod driver fails to operate. No flow from supply. Check output with flow and pressure tester. Hoses incorrectly fitted. - Page 10 www.CrowderSupply.com • Toll Free: 888-883-5144...
