Summary of Contents for Atlas Copco LPD LPD-LD
- Page 1 LPD-LD Safety and operating instructions Hydraulic post drivers © 2015 Construction Tools EOOD | No. 3392 1337 01b | 2015-01-31 Original instructions...
-
Page 3: Table Of Contents
LPD LPD-LD Contents Contents Introduction............... . 5 About the Safety and operating instructions. - Page 4 Contents LPD LPD-LD EC Declaration of Conformity (EC Directive 2006/42/EC)......19 © 2015 Construction Tools EOOD | No. 3392 1337 01b | 2015-01-31...
-
Page 5: Introduction
Safety and operating instructions Introduction Thank you for choosing a product from Atlas Copco. Since 1873, we have been committed to finding new and better ways of fulfilling our customers' needs. Through the years, we have developed innovative and ergonomic product designs that have helped customers improve and rationalize their daily work. -
Page 6: Safety Instructions
Safety and operating instructions LPD LPD-LD Drugs, alcohol or medication Safety instructions WARNING Drugs, alcohol or medication To reduce the risk of serious injury or death to Drugs, alcohol or medication may impair your yourself or others, read and understand the Safety judgment and powers of concentration. -
Page 7: Operation, Precautions
LPD LPD-LD Safety and operating instructions If you suspect that the post has struck a hidden ► WARNING Hot surfaces object, stop the machine immediately. Make sure Hydraulic oil temperatures higher than 60°C (140°F) there is no danger before continuing with the work. - Page 8 Safety and operating instructions LPD LPD-LD Work in a well ventilated area. ► WARNING Projectiles Failure of the work piece, of accessories, or even of ► If the machine has an exhaust, direct the exhaust the machine itself may generate high velocity so as to reduce disturbance of dust in a dust filled projectiles.
- Page 9 LPD LPD-LD Safety and operating instructions See the ”Noise and vibration declaration statement” WARNING Vibration hazards for the machine, including the declared vibration Normal and proper use of the machine exposes the values. This information can be found at the end of operator to vibration.
-
Page 10: Maintenance, Precautions
► Never modify the machine. Modified machines are not covered by warranty or product liability. ► Always use original parts and accessories approved by Atlas Copco. Change damaged parts immediately. ► ► Replace worn components in good time. WARNING Accessory hazards... -
Page 11: Overview
LPD LPD-LD Safety and operating instructions Overview Labels To reduce the risk of serious injury or death to The machine is fitted with labels containing important yourself or others, read the Safety instructions information about personal safety and machine section found on the previous pages of this maintenance. -
Page 12: Accumulator
Safety and operating instructions LPD LPD-LD The label indicates the guaranteed noise level Hoses corresponding to EC-directive 2000/14/EC. See "Technical data" for accurate noise level. For connection on the machine, the hydraulic hose Accumulator must be approved for a working pressure of at least 172 bar (2,500 psi) and have a 12.7 mm (½... -
Page 13: Pressure Adjustment
LPD LPD-LD Safety and operating instructions Fitting the adaptor, 65 mm (2.56 in.) Pressure adjustment 1. Fit the conical anvil rod fully home into the driving head. The maximum pressure of the power source is important. The pressure created in case of an 2. -
Page 14: Operation
Safety and operating instructions LPD LPD-LD Optional adaptors Oil supply: If the oil supply of the power source ♦ exceeds the flow prescribed, the engine's rpm must be reduced, until correct oil flow is achieved. Round adaptor: maximum Ø16 mm (Ø0.63 in.). -
Page 15: Stopping The Post Driver
LPD LPD-LD Safety and operating instructions 6. Activate the trigger by pressing the handles Before starting maintenance on the machine, clean ♦ down. When the post driver is within reach, grasp it in order to avoid exposure to hazardous the handles. -
Page 16: Every Month
Safety and operating instructions LPD LPD-LD Every month ♦ Check torque tightness of all fasteners. ♦ Check the bush in the nose casting for wear or damage. Replace if necessary. ♦ Check wear on the shank of the ramming tool. -
Page 17: Troubleshooting
LPD LPD-LD Safety and operating instructions Troubleshooting Problem Cause Solution LPD fails to operate No flow from supply Check output with flow and pressure tester Hoses incorrectly fitted Check that pressure feed is connected to P port on the LPD... -
Page 18: Technical Data
Safety and operating instructions LPD LPD-LD Technical data Machine data LPD-LD Weight kg (lb) 17.5 (38.5) Oil flow, l.p.m (gallon/minute) 20 (5,3) Working pressure, bar (psi) 80-100 (1,160-1,450) Maximum back pressure in return line, measured at post driver, bar (psi) -
Page 19: Ec Declaration Of Conformity
LPD LPD-LD Safety and operating instructions EC Declaration of Conformity EC Declaration of Conformity (EC Directive 2006/42/EC) We, Construction Tools EOOD, hereby declare that the machines listed below conform to the provisions of EC Directive 2006/42/EC (Machinery Directive) and 2000/14/EC (Noise Directive), and the harmonised standards mentioned below. - Page 24 Any unauthorized use or copying of the contents or any part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers, and drawings. www.atlascopco.com...
