Type of failure
Hard disk failure
Power cable detached, power
supply failure
CPU Controller, main board failure. Power supply is on, but there is no video output.
CPU fan failure
RAM failure

2.3 Features

8/16 port KVM over IP switch is 19" rack mount size design.
Support DOS, Win3.X, Win95/98/98SE/2000/ME/XP, WinNT, Netware, Unix, Linux
Support iMAC, Power MAC and Sun Microsystems with USB port (Need work with USB-PS/2
adapter)
Hot Plug - Add PCs or Remove Connected PCs for Maintenance without Powering Down the
KVM switch or PCs.
High Video Quality – Resolution Up To 1920X1440 (local side), 1280 X1024 (remote side)
No Software Required - easy PC selection via On Screen Display Menu (OSD), Push Buttons,
Hot Keys
At local console side - Support eight characters password protection and search PC server name
At Remove console side – Use SSL protocol for any encrypted network traffic between itself and a
connected client.
Keyboard status restored when switching PCs
LED Display for easy status monitoring
Buzzer sound for switching port confirmation.
Built-in one extra daisy chain port and no waste any PC port
No DIP switch setting needed and auto detect daisy chain bank
Manage serves around the world
KVM (keyboard, video, mouse) access over IP and analogous telephone line.
BIOS level access
No impact on server or network performance
Automatically senses video resolution for best possible screen capture
High-performance mouse tracking and synchronization
Table 2.1:Host system failures and how they are detected.
Detected by
Console screen, CMOS set-up information
Server remains in power off state after power on
command has been given.
By server specific management software
Boot-Sequence on boot console
5
8/16 PS/2 KVM over IP switch
