ASSEMBLY

Assembly requires two persons. Place all parts of the elliptical in a cleared area and remove the packing
materials. Do not dispose of the packing materials until assembly is completed.
In addition to the included tool(s), assembly requires a Phillips screwdriver
wrenches , and a rubber mallet
See the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following
the key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if
it has been preassembled. To avoid damaging parts, do not use power tools for assembly.
M6 Split Washer
(111)–12 Washer (83)–11
M8 Locknut
(102)–4
All manuals and user guides at all-guides.com
M8 Split Wave Washer
(95)–2
#10 x 13mm
Screw (59)–12
M8 x 38mm
Bolt (96)–4
M8 x 80mm Patch
Screw (84)–2
.
M8 x 25mm
Washer (98)–6
M4 x 16mm
Screw (104)–10
M8 x 56mm Patch
Screw (94)–2
M10 x 20mm Patch
Screw (66)–2
5
, two adjustable
M10 x 25mm
Washer (36)–2
M8 x 19mm Patch
Screw (82)–15
