ARTHUR HOLM DB1Twin User Manual

Hdcp compliant retractable double screen monitor for furniture integration
Hide thumbs Also See for DB1Twin:

Advertisement

Quick Links

User Guide
DB1Twin
HDCP compliant retractable double screen monitor for
furniture integration
Technology Serving Design
Danish craftmanship
Mediterranean soul

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DB1Twin and is the answer not in the manual?

Questions and answers

Summary of Contents for ARTHUR HOLM DB1Twin

  • Page 1 User Guide DB1Twin HDCP compliant retractable double screen monitor for furniture integration Technology Serving Design Danish craftmanship Mediterranean soul...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS EC REGULATIONS AND SECURITY SAFETY INSTRUCTIONS SYSTEM DESCRIPTION MOUNTING GUIDE VENEER GUIDE CONTROLS OSD MENU INPUT CONNECTORS AHNET PROTOCOL INPUT SIGNALS AHLINK INFORMATION ON DISPOSAL WARRANTY TERMS AND CONDITIONS...
  • Page 3 WELCOME Thank you for purchasing an ARTHUR HOLM product. Our product range has been designed for a seamless integration and for a maximum reliability. Please, read this installation and operating instructions carefully and keep them in a safe place for future reference.
  • Page 4 ABOUT US The Company Arthur Holm has its origins in the Danish furniture designer Jorgen Alex Jensen, who was active during the sixties and the seventies. His design inspiration and his concept of ergonomics have been continued by his family, who is the design force behind Arthur Holm product range. The...
  • Page 5: Ec Regulations And Security

    EC REGULATIONS AND SECURITY ATTENTION: Do not disassemble or modify the device in any way. This symbol warns of the presence of dangerous un-insulated voltages inside some of the components, of sufficient magnitude to expose people to risk of electronic shock. This symbol draws attention to important use and maintenance instructions in the manual that accompanies the unit.
  • Page 6 SAFETY INSTRUCTIONS Wiring connected to hazardous voltage requires installation by qualified personnel or the use of ready-made flexible cables. For your security, your equipment must be connected to an electrical outlet with grounding connection protection. Since the plug is used to disconnect the device, the operating electrical outlet must be in an easily accessible place.
  • Page 7: System Description

    DB1Twin has an extremely fast lift system with a very low noise level. Very easy to install, these monitors require no maintenance. To protect the user, DB1Twin are equipped with a safety system which stops the movements in case of resistance detection.
  • Page 8 SYSTEM DESCRIPTION Available Models MODEL DESCRIPTION HDCP compliant vertically retractable double Full HD 21,5" monitor to be integrated into furniture. Solid aluminium monitor housing in natural anodised finish. DVI-I and DVI-D inputs per each monitor (2). Interactive Setup Display allowing the control, AH22DB1Twin setup and diagnose of the monitors.
  • Page 9 SYSTEM DESCRIPTION Box Contents Before the installation of your retractable monitor, please check the contents of the shipping box, it must contain the following items: • Monitor • Power cord • Remote control (1 per 5 monitors) • Power supply 100-2 40Vac, 50-60Hz. Output 12V •...
  • Page 10: Mounting Guide

    Not complying with these direction will result in a lost of the Arthur Holm warranty. Albiral Display Solution S.L. shall not be held liable for any loss or injury incurred as a result of modifications made to goods by anyone other than the supplier or the supplier's authorised representative without the supplier's written permission.
  • Page 11 MOUNTING GUIDE Mounting table brackets Mount the table brackets below the table using the holes indicated on the corresponding Pattern Hole drawing. The screws (x6) are not supplied; The weight of the monitor is up to 25Kg. PAY ATTENTION THAT THE BRACKETS ARE MOUNTED IN THEIR CORRESPONING SIDE.
  • Page 12 MOUNTING GUIDE Mounting the monitor brackets Mount the monitor brackets on their corresponding side using the supplied screws. Mount the vertical adjustment screws (2+2) on to the monitor bracket so that the tip of the screw is flushed with the upper side of the monitor bracket.
  • Page 13 MOUNTING GUIDE Checking assembly View from below the table: View from above the monitor: Dimensions A and B in table brackets and in monitor brackets must be the same (+-1mm). If adjustment is necessary loosen 3+3 Table bracket screws, keeping always symmetry regarding to the monitor hole in the table.
  • Page 14 MOUNTING GUIDE Hanging the monitor Mount 2+2 nuts on to both table brackets as indicated on the drawing. Hang the monitor above nuts.
  • Page 15 MOUNTING GUIDE Centring the monitor Tighten each nut gradually until the monitor surface is levelled with the table surface. Air gap around the monitor have to be 2mm [0,08]. Otherwise the monitor could come in contact with the table while opening and be damaged.
  • Page 16: Veneer Guide

    VENEER GUIDE Introduction The DB1Twin device is available in a special version that is prepared to be mounted from below the table with a Veneer finishing on the top of the monitor to match the table. The Veneer is not supplied.
  • Page 17 VEENER GUIDE Veener The Veneer can be placed in three ways (Dimensions are specified in the corresponding “Pattern Hole” document): Option 1: Veneer: In order to adjust the plastic touch button height, Venneer + Glue/ tape thickness must be previously communicated. Option 2: Veneer + Distance Plate: For Veneers Thickness of 1mm [0,04] or less.
  • Page 18 VEENER GUIDE Veener The Veneer can be placed in three ways (Dimensions are specified in the corresponding “Pattern Hole” document): Option 3: Veneer: The veneer thickness must be 5mm [0,16 – 0,19]. A mechanized blind hole will be necessary to hide the touch button copper cylinder.
  • Page 19 VEENER GUIDE Veener Option 1: - Veneer thickness must be accorded with factory 1. Check if the Veneer fits perfectly with the monitor. To join both parts correctly it is important that the two surfaces are touching each other in the whole length.
  • Page 20 VEENER GUIDE Veener Option 2: - Distance Plate material can’t be metallic. Wood or DM are advisable. - Veneer material can’t be conductor. 1. Check if the Distance Plate fits perfectly with the monitor. The copper cylinder can’t project outwards from the Distance Plate surface. If so, the copper cylinder can be gently filed down till aligns with the Distance Plate surface.
  • Page 21 5. Glue the Veneer. Double side tape or glue can be used (depending on the kind of materials are going to be The total thickness of Veneer + glue used can’t be thicker than 1mm [0.04]. Veener Option 2 Cut-Out: DB1Twin Veneer cut-out: DB1Twin Distance plate cut-out:...
  • Page 22 VEENER GUIDE Veener Option 3: - Veneer material can’t be conductor. 1. Check if the Veneer fits perfectly with the monitor. To join both parts correctly it is important that the two surfaces are touching each other in the whole length. If there is a gap between the Veneer and the monitor, check if the hole depth in the Veneer is correct.
  • Page 23: Controls

    CONTROLS Remote control POWER Switch ON/OFF the monitor MENU Activates the OSD menu on screen Control up on the OSD menu DOWN Control down on the OSD menu LEFT Control left on the OSD menu RIGHT Control right on the OSD menu Selects the function on the OSD menu.
  • Page 24 CONTROLS IR sensor The IR sensor is located on the lower side of the screen. Monitor movement controls On the monitor's top frame, there are two buttons to control the up and down monitor movements. 1. Rising the monitor: Be aware that no objects or parts of the body are one the surface of the top monitor's frame and which could obstruct the rising of the display.
  • Page 25: Osd Menu

    OSD MENU Accessing the menu system • With the OSD off, push the MENU button to activate the main OSD menu. • Press the UP and DOWN buttons to move from one function to another. Please refer to the following sections below to view a complete list of all the functions available for the monitor.
  • Page 26 OSD MENU Noise Reduction: Adjusts the image noise filter ∙ Off ∙ Low ∙ Medium ∙ High ∙ Default Screen: (Only for analogue signals) ∙ Auto Adjust ∙ Horizontal Position ∙ Vertical Position ∙ Size ∙ Phase Backlight: Adjusts the backlight screen's level Colour Range: Adjusts the colour range ∙...
  • Page 27 OSD MENU Option Language: OSD language selection Restore Factory Default: Adjusts the parameters to the initial factory parameters Blending: OSD window transparency ∙ Low ∙ Medium ∙ High ∙ Off OSD Duration: Adjusts the time that the OSD menu window remains on the screen Software Update (USB): Port to use for firmware's upgrade.
  • Page 28: Input Connectors

    INPUT CONNECTORS 12V D.C.: Power supply input connector. XLR-4 connector. - 1,2: Ground - 3,4: 12Vdc GPI: Monitor external contact close control. SubD9 female. 1 . GPI1 + 2. GPI1 – 3. GPI2 + 4. GPI2 – 5. GPI3 – 6.
  • Page 29 INPUT CONNECTORS DVI 1/ DVI A: DVI-I input signal. Connect a DVI (digital) input signal and select DVI 1 on the OSD monitor menu. Use a DVI to VGA adaptor to connect an ARGB (analogue) input signal and select DVI-A on the OSD monitor menu.
  • Page 30: Ahnet Protocol

    AHNET PROTOCOL Communications protocol COMMUNICATION RS422 CONNECTION RJ45 WIRING CAT-6 Speed and configuration BAUD RATE 38400 DATA BITS PARITY NONE STOP BITS Wiring Diagram 1. Data TX + 2. Data TX – 3. Data RX + 4. NC 5. NC 6 .Data RX –...
  • Page 31 AHNET PROTOCOL AHnet protocol Uses 5 bytes communication: BYTE 0 START BYTE BYTE 1 ADDRESS BYTE BYTE 2 COMMAND BYTE BYTE 3 VALUE 1 BYTE 4 VALUE 2 Commands COMMAND DESCRIPTION RESPONSE FA XX 01 01 00 GO UP FB XX 01 01 00 FA XX 01 00 00 GO DOWN FB XX 01 00 00...
  • Page 32 AHNET PROTOCOL BITE CLOSED OPENED SCREEN ON SCREEN OFF DVI-A DVI 1-D DVI 2-D PROTECTION STOP MONITOR OK BITE BUTTON LOCK BUTTON UNLOCK...
  • Page 33 AHNET PROTOCOL Picture Commands COMMAND DESCRIPTION RESPONSE FA XX 15 00 00 ASK FOR BACKLIGHT LEVEL FB XX 15 00 ZZ FA XX 16 00 00 ASK FOR CONTRAST LEVEL FB XX 16 00 ZZ FA XX 17 00 00 ASK FOR BRIGHTNESS LEVEL FB XX 17 00 ZZ Number of the monitor address.
  • Page 34: Input Signals

    INPUT SIGNALS RESOLUTION Horizontal freq (KHz) Vertical freq (Hz) Scanning type 800x600@60Hz 37.879 60.317 Progressive 800x600@72Hz 48.077 72.188 Progressive 800x600@75Hz 46.875 75.000 Progressive 1024x768@60Hz 48.363 60.005 Progressive 1024x768@70Hz 56.476 70.070 Progressive 1024x768@75Hz 60.023 75.030 Progressive 1280x720@60Hz 44.697 59.915 Progressive 1280x768@60Hz 47.396 59.995 Progressive...
  • Page 35: Ahlink

    AHLINK AHlink is used to control and set-up the unit. By default, the AHlink signal on the unit is deactivated. To activate the AHlink signal, press for 5 seconds the external Up and Down screen buttons located on the top monitor frame or press for 5 seconds the UP and Down contact close on the GPI connector.
  • Page 36 AHLINK If the device does not appear on the window, the AHlink signal is not active. The AHlink name always begins with AH characters and the fourth last MAC AHlink address. Select the device to control and set-up the unit. When selecting the device, the first page will upload on the mobile phone.
  • Page 37 AHLINK SERIAL Serial number of the unit Firmware version Controls the Up and Down monitor movements DISP: Turns the display ON or OFF DVIA, DVI1, DVI2: Input source selection BACKL: Configuration of the display's backlight CONTR: Configuration of the display's contrast BRIGHT: Configuration of the display's brightness...
  • Page 38: Information On Disposal

    INFORMATION ON DISPOSAL FOR USERS OF WASTE ELECTRICAL & ELECTRONIC EQUIPMENT This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be mixed with general household waste. For proper treatment, recovery and recycling, please take these products to the designated collection points, where they will be accepted on a free of charge basis.
  • Page 39: Warranty Terms And Conditions

    WARRANTY TERMS AND CONDITIONS Albiral Display Solutions warrants this product against manufacturing defects and workmanship for a period of five (5) years from the date of purchase, subject to the conditions below. Mechanical parts: The engine and the product’s mechanical parts are warranted against manufacturing defects and workmanship for a period of five (5) years from the date of purchase.
  • Page 40 If you have any doubts concerning the terms of this warranty, please contact: business@albiral.com +34 938 502 376 Copyright © Dec. 2019. All rights reserved Albiral Display Solutions SL. Registered trademarks: Albiral, Arthur Holm, Pixtron Broadcast...
  • Page 41 Patents P27178ITEP P27178RUPC MU17180ES00 P27178USPC MU17301ES00 P27284DEEP MU17322ES00 P27284EPPC MU17413ES00 P27284ESEP MU17445ES00 P27284GBEP MU17854ES00 P27284RUPC MU17868DEPC P27284USPC MU17868RUPC P27715ESEP P24821DEEP P28089DEEP P24821ESEP P28089ESEP P24821GBEP Fàtima 25, Sant Hipòlit de Voltregà P28089ITEP P24821USPC 08512 Barcelona – Spain P28089USPC P27178DEEP tel: +34 93 850 23 76 / 23 83 P28090EP00 P27178EPDV01 fax: +34 93 850 25 50 / 23 72...
