SM 110

3.6 PLU Programming

The following items can be programmed in PLU PROGRAMMING mode. The format chosen for the
PLU will decide what items can be programmed in the PLU file. The items which print areas are not set
on the selected format will skip automatically or not printed on label. (If the item doesn't appear on the
PLU programming, check whether the parameter is set to ENABLE in Program / Skip Item Data).
PLU file for weighing item and non-weighing item listed below can be programmed according to the
following order.
Weighing Item
Step PLU File (weighing Item)
S1.0 PLU No.
S1.1 Unit Price (6 digits)
S1.2 Label Format for the 1st label
S1.3 Label Format for the 2nd label
S1.4 Commodity Name Font Size
S1.4 Commodity Name
S1.5 Selection of ITF Barcode Format
S1.6 Bar Code Selection
S1.7 Flag data
S1.8 Item Code No.
S1.9 Item Code No. (Lower 4 digits)
S1.10 Right Side Data of Item Barcode
S1.11 Selection of EAN ADD-ON
S1.12 Main Group No.
S1.13 Select whether to print Sell by date
S1.14 Sell by date (Days after the current date)
S1.15 Select whether to print Sell by time
S1.16 Select key-in data or present time
S1.17 Sell by Time (If Key-In is selected)
S1.18 Select whether to print Used by date
S1.19 Used by date (days after Packed date)
S1.20 Select whether to print Packed date
S1.21 Packed Date (days after actual packed date)
S1.22 Select whether to print Packed time
All manuals and user guides at all-guides.com
Refer to Label Format List.
Free format No.1~99 only.
* Digits of Flag and Item data can be selected in the barcode type
selection in S1.6.
Only when Item Code is more than 6 digits.
Only when Spec02 set to 3.
* If No Print is selected, Sell- by Date in S1.12 is skipped.
* If No Print is selected, Key in selection in S1.14 Sell-by time in
S1.15 is skipped.
* If S1.14 select CLOCK TIME, Key in selection in S1.15 is
skipped.
* If No Print is selected, Used- by Date in S1.17 is skipped.
* If No Print is selected, Packed Date in S1.19 is skipped.
* If No Print is selected, Key-in selection in S1.21 Packed time in
S1.22 are skipped.
26
PROGRAM MODE
Remarks
