SM 110

3.3 Department Files

Department file is used for categorizing Main Groups. Department Number between 1 ~ 99 are
available for programming. The Main Groups that are not linked to any Department will be assigned to
Department Number 97 automatically. Maximum 16 characters per file are available and each with 1
line.

3.3.1 Program Department File

OPERATION
PT
[MODE][MODE]
[MODE]
[2] or [X]、[》]
[*] S2.0
[1] S2.0
[*] S2.1
[M][E][A][T] S2.1
[PLU]
Note1: Number after "NAME" in Total display shows the position of the cursor.
Note2: The DEPT. No.1 to No.99 are available for programming.
(No.97 is default No. for PLU programming, and the PLUs which are not linked to any DEPT No. are assigned
to No.97)
(Non-PLU files (Weighing items) are assigned to DEPT code No.98)
(Non-PLU files (Non-weighing items) are assigned to DEPT code No.99)
Note3: The Department names programmed are not printed on the label/receipt but are for reporting.
All manuals and user guides at all-guides.com
DISPLAY
kg ＄/kg
S1 PLU
→
S2 → DEPT
DEPT 0
DEPT 1
DEPT
DEPT MEAT
S2 → DEPT
20
PROGRAM MODE
REMARK
＄
Enter S mode.
FILE
Lamp S turns on.
Select Department Programming.
FILE
＄ /kg window displays DEPT.
NO SET
code.
NO SET Enter department No.(Ex. [1])
Enter department programming,
NAME 0
set the department name.
Enter DEPT. name(use letter
keys)(Ex. "MEAT" for Dept. No
1)
NAME 4
The methods of ASII letter input
refer to 3.23 ASSII Character Input
Method.
Store the department file, back to S
FILE
mode.
