- Page 1 DIGIMANO 1000 DigiMano 1000 Pressure Vacuum Meter INSTRUCTION MANUAL Netech Corporation 110 Toledo St, Farmingdale, NY 11735, http://www.NetechCorp.us http://www.PressureMeter.com...
-
Page 2: Table Of Contents
User Manual DigiMano 1000 Contents ..............Warranty ....................... 3 Notices (Patents / Copy Right, Trademarks) ............4 Quality Assurance ....................4 Calibration ......................4 Safety Considerations ..................4 Returns & Credits ....................5 Repair and Recalibration ..................6 Models and Part Numbers ................... 7 Optional Accessories .................... -
Page 3: Warranty
Netech Corporation. Only serialized products are covered under this warranty. This warranty does not apply if the product has been damaged by accident or misuse or as the result of service or modification by other than Netech Corporation, or if its serial number is defaced or removed. -
Page 4: Notices (Patents / Copy Right, Trademarks)
DigiMano 1000 Notices Patents / Copyright Copyright © 2012 by Netech Corporation. All rights reserved. No part of this publication may be reproduced or transmitted in any form other than for the purchaser’s personal use without written permission from Netech Corporation. -
Page 5: Returns & Credits
Return Procedure All items being returned (including all warranty-claim shipments) must be sent freight- prepaid to our factory location. When you return an instrument to Netech Corporation, we recommend using United Parcel Service, Federal Express, DHL or Air Parcel Post. -
Page 6: Repair And Recalibration
User Manual DigiMano 1000 Returns for Refund / Credit A Return Material Authorization (RMA) number must be obtained from our service or customer service dept, before a product is returned for refund or credit. The RMA number should be clearly marked on the package along with a statement indicating the reason for return. -
Page 7: Models And Part Numbers
DIGIMANO 1000 Models and Part Numbers Part Number Description DigiMano 1000, 2000 IN - Pressure Vacuum Meter, Range 200-2000IN of 1999 mmHg and 199.9 in H2O, Accuracy 0.25% FSO DigiMano 1000, 2000 PS - Pressure Vacuum Meter, Range 200-2000PS of 1999 mmHg and 19.99 PSI, Accuracy 0.25% FSO... -
Page 8: General Overview
The versatile instrument presents its measurement results in one of two engineering units on a large 3 _ digit LCD display. The DigiMano 1000 has an accuracy of 0.25% full scale. Three Models with different engineering units and pressure ranges are available. -
Page 9: General Operation
DIGIMANO 1000 General Operation DigiMano Pressure Meter Figure 1 Controls & Indicators 1. Display: A 3_ Digit LCD indicates the result of the measurement being made. 2. On-Off Switch: Turns instrument on and off. 3. Unit Selector Switch: Selects desired units of measurement. -
Page 10: Operating Instruction
User Manual DigiMano 1000 Operating Instructions: 1. Turn the DigiMano 1000 ON and allow two minutes for the transducer to warm up and stabilize. 2. Select the desired engineering unit to be displayed. 3. With no pressure applied the display should read zero (0). If not, adjust the manual zero adjustment potentiometer. -
Page 11: Maintenance And Storage
Maintenance and Storage Calibration / Service The mechanical assembly of DigiMano 1000 contains no parts that can be serviced by the user. The unit should be returned to Netech Corporation for repair or calibration. The alignment and adjustment parameters are critical to the robust and efficient performance of the unit and can be performed only at the factory. - Page 12 User Manual DigiMano 1000 Appendix This section is intentionally left blank for future use...
