10.2.4. 480 – 525 Volt (+/- 10%), 3 phase Input, 3 Phase Output
Frame Power
Size Rating
kW
7 132
7 160
7 185
7 200
10.2.5. 500 – 600 Volt (+ / - 10%), 3 Phase Input, 3 Phase Output
Frame Power
Size Rating
kW
2 0.75
2 1.5
2 2.2
2 4
2 5.5
3 7.5
3 1 1
3 15
4 18.5
4 22
4 30
5 37
5 45
6 55
6 75
6 90
6 1 10
NOTE
 R atings shown above apply to 40°C Ambient temperature. For derating information, refer to section 10.5. 1 . Derating for Ambient
Temperature
 T he drive is protected against short-circuit from power output to protective earth for all rated cable lengths, cable sizes and cable types.
 3 phase drive can be connected to single phase supply when the output current is 50% derated.
 T he maximum cable lengths stated here are based on hardware limitations and do NOT take into consideration any requirements
for compliance to any EMC standards. Please see section 4. 1 3. EMC Compliant Installation for further information.
 T he maximum motor cable length stated applies to using a shielded motor cable. When using an unshielded cable, the maximum
cable length limit may be increased by 50%. When using the Invertek Drives recommended output choke, the maximum cable
length may be increased by 100%.
 T he PWM output switching from any inverter when used with a long motor cable length can cause an increase in the voltage at the
motor terminals, depending on the motor cable length and inductance. The rise time and peak voltage can affect the service life of the
motor. Invertek Drives recommend using an output choke for motor cable lengths of 50m or more to ensure good motor service life.
 F or IP20 Frame Size 8 the Vector Speed and Torque control modes may not operate correctly with long motor cables and output filters.
It is recommended to operate in V/F mode only for cable lengths exceeding 50m.
 S upply and motor cable sizes should be dimensioned according to local codes or regulations in the country or area of installation.
10
 F or UL compliant installation, use Copper wire with a minimum insulation temperature rating of 70°C, UL Class CC or Class J Fuses
(exception: Eaton Bussmann FWP series must be used for size 6A & 6B IP20 models).
74 | Optidrive P2 User Guide | Version 3.07
Input Fuse or MCB
Current (Type B)
HP A Non UL
192 250
215 315
262 315
275 400
Input Fuse or MCB
Current (Type B)
HP A Non UL
1 2.5 10
2 3.7 10
3 4.9 10
5 7.8 10
7.5 10.8 16
10 14.4 16
15 20.6 25
20 26.7 32
25 34 40
30 41.2 50
40 49.5 63
50 62.2 80
60 75.8 100
75 90.9 125
100 108.2 125
125 127.7 160
150 160 200
Maximum Cable
Size
UL mm AWG/kcmil
150 300MCM
150 300MCM
150 300MCM
150 300MCM
Maximum Cable
Size
UL mm AWG/kcmil
6 8 8
6 8 8
10 8 8
10 8 8
15 8 8
20 8 8
30 8 8
35 8 8
45 16 5
60 16 5
70 16 5
80 35 2
100 35 2
125 150 300MCM
150 150 300MCM
175 150 300MCM
200 150 300MCM
Rated Maximum Recommended
Output Motor Cable
Current Length
A m ft
185 100 330
205 100 330
255 100 330
275 100 330
Rated Maximum Recommended
Output Motor Cable
Current Length
A m ft
2. 1 100 330
3. 1 100 330
4. 1 100 330
6.5 100 330
9 100 330
12 100 330
17 100 330
22 100 330
28 100 330
34 100 330
43 100 330
54 100 330
65 100 330
78 100 330
105 100 330
130 100 330
150 100 330
