Sumitomo Drive Technologies Invertek Drives Optidrive P2 Manual page 59

Par. Function
P6-01
Firmware Upgrade Enable
P6-02
Thermal Overload Management
P6-03
Auto Reset Time Delay
P6-04
Relay Output Hysteresis
P6-05
Encoder Feedback Enable
P6-06
Encoder PPR
P6-07
Speed Error Trip Threshold
P6-08
Max Speed Reference Frequency
P6-09
Speed Droop Control
P6-10
Function Block Program Enable
P6-11
Speed Hold Time on Enable
P6-12
Speed Hold / DC Injection Time on Disable
P6-13
Hoist Brake Release Time
P6-14
Hoist Brake Apply Time
P6-15
Hoist Brake Pre-Torque Level
P6-16
Hoist Pre-Torque Time Limit
P6-17
Maximum Torque Time Limit
P6-18
DC Injection Braking Current
P6-19
Brake Resistor Resistance
P6-20
Brake Resistor Power
P6-21
Brake Chopper Ut Duty
P6-22
Reset Fan Run Time
P6-23
Reset Energy Meters
P6-24
Maintenance Time Interval
P6-25
Reset Maintenance Indicator
P6-26
Analog Output 1 Scaling
P6-27
Analog Output 1 Offset
P6-28
P0-80 Display Index
P6-29
User Default Parameters
P6-30
Level 3 (Advanced) Access Code
www.invertekdrives.com
Setting Range
0 Disabled
1 Update I/O & P/S
2 Update I/O
3 Update P/S
4 – 32kHz (Model Dependent)
1 – 60 Seconds
0.0 – 25.0%
0 Disabled
1 Enabled
0 - 65535
0.0 – 100.0%
0 – 20kHz
0.0 – 25.0%
0 Disabled
1 Enabled
0 – 250s
0 – 250s
0.0 – 5.0s
0.0 – 5.0s
0.0 – 200.0%
0.0 – 25.0s
0.0 – 25.0s
0.0 – 100.0%
Model Dependent
Model Dependent
0.0 – 20.0%
0 No Reset
1 Reset
0 No Reset
1 Reset
0 – 60000 Hours
0 No Reset
1 Reset
0.0 – 500.0%
-500.0 – 500.0%
0 - 200
0 No Function
1 Save user parameters
2 Clear user parameters
0 – 9999
Version 3.07 | Optidrive P2 User Guide | 59
Default Notes
0 This parameter should not be
adjusted by the user.
4 kHz Minimum Effective Switching
Frequency.
20s
0.3%
0
0
5.0%
0 kHz
0.0%
0
0s
0s
0.2s
0.3s
8.0%
5.0s
0.0s
0.0% This function is active only
for Induction Motors (IM)
and Synchronous Reluctance
Motor (SyncRM).
2.0%
0
0
0 Hours
0
100.0%
0.0%
0
0
201
8
