  • Page 1 Series Embedded System User’s Manual...
  • Page 2 Disclaimers This manual has been carefully checked and believed to contain accurate information. Axiomtek Co., Ltd. assumes no responsibility for any infringements of patents or rights of any third party, and any liability arising from such use. Axiomtek does not warrant or assume any legal liability or responsibility for the accuracy, completeness or usefulness of any information in this document.

  • Page 3: Safety Precautions

    Safety Precautions Before getting started, please read the following important safety precautions. User should not modify any unmentioned jumper setting without Axiomtek FAE’s instruction. Any modification without instructions might damage the system. The tBOX400-510-FL does not come equipped with an operating system. An operating system must be loaded first before installing any software into the computer.

  • Page 4: Classification

    Classification Degree of production against electric shock: not classified Degree of protection against the ingress of water: IP30 Equipment not suitable for use in the presence of a flammable anesthetic mixture with air or with oxygen or nitrous oxide. Mode of operation: Continuous General Cleaning Tips You may need the following precautions before you begin to clean the computer.
  • Page 5 Cleaning Tools: Although many companies have created products to help improve the process of cleaning your computer and peripherals users can also use household items to clean their computers and peripherals. Below is a listing of items you may need or want to use while cleaning your computer or computer peripherals.
  • Page 6 Scrap Computer Recycling Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in case computers require maintenance or repair; or for recycling in case computers are out of order or no longer in use. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd.

  • Page 7: Table Of Contents

    Table of Contents Safety Precautions ....................iii Classification ......................iv CHAPTER 1 INTRODUCTION ............... 1 General Description ................1 System Specifications ............... 2 1.2.1 CPU ........................2 1.2.2 System I/O ......................2 1.2.3 System Specification ..................2 1.2.4 Driver CD Content .................... 3 Dimensions ..................
  • Page 8 This page is intentionally left blank. viii...

  • Page 9: Chapter 1 Introduction

    Series User’s Manual CHAPTER 1 INTRODUCTION This chapter contains general information and detailed specifications of the tBOX400-510-FL. Chapter 1 includes the following sections:  General Description  System Specification  Dimensions  I/O Outlets  Package List General Description ®...

  • Page 10: System Specifications

    Series User’s Manual System Specifications 1.2.1  ™ ® Celeron-3965U / Core™ i3-7100U / i5-7300U / i7-7600U  Onboard Intel Core processor (2.2 up to 2.8 GHz)  BIOS  American Megatrends Inc. BIOS. “Load Optimized Default”: Allows the user to back up customized settings in the ...

  • Page 11: Driver Cd Content

    Series User’s Manual  Operation Temperature  -40°C ~ +60°C (- 40ºF ~ 158ºF) with W.T. SSD  -25°C ~ +55°C (+13°F ~ +131°F) with HDD  Storage Temperature  -40°C ~ +85°C (- 40ºF ~ 176ºF)  Humidity ...

  • Page 12: Dimensions

    Series User’s Manual Dimensions The following diagrams show the dimensions and outlines of the tBOX400-510-FL. Introduction...
  • Page 13 Series User’s Manual ▲ 24-110VDC-in railway application ▲ 24VDC-in marine application Introduction...

  • Page 14: I/O Outlets

    Series User’s Manual I/O Outlets The following figures show the I/O outlets on the front and rear views of the tBOX400-510-FL.  Front View Introduction...
  • Page 15 Series User’s Manual  Rear View Introduction...
  • Page 16 Series User’s Manual  Board Layout Introduction...

  • Page 17: Packing List

    Series User’s Manual Packing List The package bundled with your tBOX400-510-FL should contain the following items:  tBOX400-510-FL system unit x 1  Quick Installation Guide x 1  DVD x 1 (for drivers)  Screw pack x 1 ...
  • Page 18 Series User’s Manual This page is intentionally left blank. Introduction...

  • Page 19: Chapter 2 Hardware Installation

    Series User’s Manual CHAPTER 2 HARDWARE INSTALLATION The tBOX400-510-FL is designed for easy hardware configurations, such as the HDD (Hard Disk Drive), DRAM and mini PCIe card. Chapter 2 will show you how to install the hardware. Installing the Swappable HDD/SSD Step 1 Attach a piece of Mylar on the back of an HDD/SSD as shown.

  • Page 20: Installing The Ddr Module And Express Mini Card

    Series User’s Manual Installing the DDR module and Express Mini Card Step 1 Make sure system power is off and unplug the power cord. Step 2 Turn the tBOX400-510-FL upside down, loosen the cover screws and lift the bracket a little bit as shown.
  • Page 21 Series User’s Manual Step 5 Install the DDR module with caution and put the thermal pad on the DDR module again. Then screw the DDR cover to finish the installation. Hardware Installation...
  • Page 22 Series User’s Manual For the Express Mini Card: Step 1 Slide a SIM or Mini Card into their respective slot with caution. Step 2 Fasten the screws to complete the installation. For the External Power Supply Unit Model name...

  • Page 23: Chapter 3 Connector

    Series User’s Manual CHAPTER 3 CONNECTOR Connectors Connectors connect the CPU board with the other parts of the system. Loose or improper connection might cause problems. Make sure all connectors are properly and firmly connected before you turn on the system.

  • Page 24: Serial Port Connector

    Series User’s Manual 3.1.2 Serial Port Connector The COM1 port connector is a DB9 connector. The pin assignment of RS-232/RS-422/RS- 485 is listed in the following table. If you need a COM port to support RS-422 or RS-485, please set it up in BIOS settings.

  • Page 25: Led Indicators

    Series User’s Manual 3.1.4 LED Indicators LED Indicator Function PWR/ Green Power on HDD/ Blue HDD activity PL1/ Green Programmable PL2/ Green Programmable 3.1.5 DC Power Input Connector The DC-in connector has three pins as shown in the table below.

  • Page 26: Lan Connector

    Series User’s Manual 3.1.6 LAN Connector The RJ-45 LAN connectors can support 10/100/1000Mbps Ethernet Description 10/100Base-T 1000Base-T Transmit Data+ or Bidirectional BI_DA+ BI_DA- Transmit Data- or Bidirectional BI_DB+ Receive Data+ or Bidirectional N.C. BI_DC+ Not Connected or Bidirectional N.C.

  • Page 27: Sim Card Connector (Cn8,Cn9)

    Series User’s Manual The M12 4-pin LAN connector is an A-coded type and is able to support 10/100/1000Mbps. 10/100 Mbps 1000 Mbps MDI 2+ MDI 3+ MDI 3- TX - MDI 0- RX + MDI 1+ M12-A Code 8-Pin/ Female...

  • Page 28: Pci-Express Mini Card Connector (Cn12)

    Series User’s Manual 3.1.8 PCI-Express Mini Card Connector (CN12) This is a full-size PCI-Express Mini Card connector on the top side complying with PCI- Express Mini Card Spec. V1.2. It supports either PCI-Express or SATA (mSATA). Since the default setting is mSATA Mini Card, if PCI-Express is needed to insert, please refer to section 4.4 to change the setting.

  • Page 29: Pci-Express Mini Card Connector (Cn6,Cn7)

    Series User’s Manual 3.1.9 PCI-Express Mini Card Connector (CN6,CN7) This is a PCI-Express Mini Card connector on the top side supporting PCI-Express x1 and USB 2.0. It complies with PCI-Express Mini Card Spec. V1.2. Signal Signal WAKE# +3.3VSB No use No use +1.5V...

  • Page 30: 3.1.10 Antenna Opening

    Series User’s Manual 3.1.10 Antenna Opening Profile opening is reserved for Wi-Fi/3G/4G antennas. 3.1.11 HDD Tray Locker Locks and secures the swappable HDD/SSD bay. Status Diagram Unlocked Locked 3.1.12 Remote Switch Connector The remote switch is ideal for a remote button which can act as an ATX power on/off button.

  • Page 31: Chapter 4 Ami Bios Setup Utility

    Series User’s Manual CHAPTER 4 AMI BIOS SETUP UTILITY This chapter provides users with detailed descriptions of how to set up basic system configuration through the AMI BIOS setup utility. Starting To enter the setup screens, follow the steps as below: Turn on the computer and press the <Del>...

  • Page 32: Navigation Keys

    Series User’s Manual Navigation Keys The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup utility hot keys can be used at any time during the setup navigation process. These keys include <F1>, <F10>, <Enter>, <ESC>, <Arrow> keys, and so on.

  • Page 33: Main Menu

    Series User’s Manual Main Menu System Time/Date Use this option to change the system time and date. Highlight System Time or System Date using the <Arrow> keys. Enter new values through the keyboard. Press the <Tab> key or the <Arrow>...

  • Page 34: Advanced Menu

    Series User’s Manual Advanced Menu The Advanced menu allows users to set the configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus: ►...
  • Page 35 Series User’s Manual Mini Card Switch Select the PCIe / mSATA function. CPU Configuration This screen shows the CPU configuration. AMI BIOS Setup Utility...
  • Page 36 Series User’s Manual SATA Configuration Set SATA configuration. SATA Controller (S) Enable or disable the integrated SATA controllers. (Default: Enabled) SATA Mode Choose the SATA operation mode. Here are the options for your selection . Serial-ATA Port 0-3 Control the onboard SATA port. Here are the options for your selection: enabled and disabled.
  • Page 37 Series User’s Manual PCH-FW Configuration Configure Intel(R) Active Management Technology Parameters. Display ME firmware version and ME firmware SKU. AMI BIOS Setup Utility...
  • Page 38 Series User’s Manual USB Configuration This screen shows the USB Device. This is for supporting USB devices on legacy OS. The system will automatically detect any USB device connected to the computer and enable the USB legacy mode. AMI BIOS Setup Utility...
  • Page 39 Series User’s Manual Serial Port Console Redirection The settings specify how the host computer and the remote computer (which the user is using) will exchange data. Both computers should have the same or compatible settings. AMI BIOS Setup Utility...
  • Page 40 Series User’s Manual F81803 Super IO Configuration Set up options for the Super IO Configuration, and change the value of the selected option AMI BIOS Setup Utility...
  • Page 41 Series User’s Manual Serial Port 1 Configuration Serial Port Enable/Disable serial port COM Port Type This option is used to select the RS-232/422/485 function. AMI BIOS Setup Utility...
  • Page 42 Series User’s Manual Hardware Monitor This screen shows the Hardware Health configuration. AMI BIOS Setup Utility...

  • Page 43: Chipset Menu

    Series User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. AMI BIOS Setup Utility...
  • Page 44 Series User’s Manual System Agent (SA) Configuration Memory Configuration This screen shows the memory information. AMI BIOS Setup Utility...

  • Page 45: Security Menu

    Series User’s Manual Security Menu The security menu allows users to change the security settings for the system. Administrator Password This item indicates whether an administrator password has been set. It will show “Installed” if a password has been set or “Not Installed” if no password has been set.

  • Page 46: Boot Menu

    Series User’s Manual Boot Menu The Boot menu allows users to change boot options of the system. You can select any of the items in the left frame of the screen to go to the sub menus: Setup Prompt Timeout Set the timeout length to wait before entering the Setup menu during system power-on.

  • Page 47: Save & Exit Menu

    Series User’s Manual Save & Exit Menu This option allows users to operate optimized settings, customized settings and restore default settings for system configuration. Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and continue start-up procedures, so the new system configuration parameters can take effect.
  • Page 48 Series User’s Manual Save Changes This option allows you to save all the values and changes you set. Discard Changes This option allows you to abandon all the values and changes you set. Restore Defaults It automatically sets all Setup options to a complete set of default settings when you select this option.

  • Page 49: Appendix Awatchdog Timer

    Series User’s Manual APPENDIX A WATCHDOG TIMER What is Watchdog Timer The integrated W atchdog Timer can be set up by programming. There are 1~255 levels available. After initializing W atchdog Timer by setting a countdown value, the countdown of the value will start automatically when W atchdog Timer is enabled.
  • Page 50 Series User’s Manual N=79h, the time base is set to minute. Sample of Watchdog application Assume that program A must be kept running for a specified period of time: 1. Initialize W atchdog Timer with a countdown time value bigger than the running time of program A.
