88 5002 691
Buffet
Important NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occurring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
C.
Shelf
4 pcs.
For assembly see instructions in carton : 88 5002 692
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
D.
Back Panel
2 pcs.
A.
Top
1 pc.
B.
Bottom
1 pc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Styles 88 5002 691
Summary of Contents for Home Styles 88 5002 691
- Page 1 Part List 1 pc. Bottom 1 pc. Shelf 4 pcs. Back Panel 2 pcs. For assembly see instructions in carton : 88 5002 692 Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 2 1 pc. 4 pcs. 16 pcs. (+1 extra) 4 pcs. Also need Parts in carton : 88 5002 691 Tools required for assembly : Phillips screwdriver Tools recommended for assembly : Leve Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 3 Assembly Instruction 2 / 6 IMPORTANT * Do not tighten up all the screws until each part is properly assembled. * You should keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future. * Use a soft cloth between these parts and the fl...
- Page 4 Assembly Instruction 3 / 6 Cam Lock STEP 2 Attach Front Post (M) to Side Panel (E) and Front Post (N) to Cam Lock Side Panel (F) with Cam Locks. (See Figure 2) Magnet Wood Screw for Magnet Cam Lock Figure 2 Figure 3 STEP 3...
- Page 5 Assembly Instruction 4 / 6 STEP 4 Cam Lock Attach Back Rail (J) to Side Panel unit (F) with Cam Lock then slide Back Panel (D) into place. Attach Back Rail (I) to Side Panel unit (F) with Cam Lock then slide Back Panel (D) into place.
- Page 6 Assembly Instruction 5 / 6 STEP 7 Head Cap Bolt Place Top (A) onto the unit and Cam Lock attach with Head Cap Bolts and Cam Locks. (See Figure 5) Slide Drawers (O) into position. Insert Adjustable Pins into side panels at the desired level.
- Page 7 Assembly Instruction 6 / 6 Drawer (O) STEP 1 Figure 1 Attach O1 to O3 and O4, using a Phillips screwdriver and long wood screws (4X), tighten MAKE SURE ROLLER halfway. IS ON THE BACK Attach O2 to O3 and O4 using Figure 2 long wood screws (4X), tighten halfway.
