Kitchen Island Combo
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top Unit
1 pc.
For assembly see instructions in carton 88 5002 943
Tools required for assembly : Phillips screwdriver
Advertisement
Table of Contents
Related Manuals for Home Styles 88 500 941 Series
Summary of Contents for Home Styles 88 500 941 Series
- Page 1 88 500x 941 Kitchen Island Combo IMPORTANT NOTE Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damages occuring to the wood parts. We have taken great care in the design of this product and request that you carefully and strictly follow our assembly instructions to ensure a completed product as it was designed.
- Page 2 88 500x 942 Kitchen Island Combo IMPORTANT NOTE Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damages occuring to the wood parts. We have taken great care in the design of this product and request that you carefully and strictly follow our assembly instructions to ensure a Casual Attire For Today's Home...
- Page 3 88 500x 943 Kitchen Island Combo IMPORTANT NOTE Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damages occuring to the wood parts. We have taken great care in the design of this product and request that you carefully and strictly follow our assembly instructions to ensure a completed product as it was designed.
- Page 4 Assembly Instructions 2/4 IMPORTANT Do not tighten up all the screws until each part is properly assembled. You should keep Hex Wrench in the safe place as you may need to tighten up the Head Cap Bolts in the future. STEP 1 Cam Lock Screw Put Cam Lock Screws into the pre-drilled holes of Leg (K),(L) and tighten.
- Page 5 Assembly Instructions 3/4 Head Cap Bolt STEP 3 Attach unit from Step 2 and Middle Panel (E) to Base (H) with Head Cap Bolts. Head Cap Bolt STEP 4 Attach Leg (I) and (J) to Base (H) with Head Cap Bolts. Slide Side Panels (M) into position.
- Page 6 Assembly Instructions 4/4 Head Cap Bolt STEP 5 Attach Rail (F) to unit Machine Screw with Head Cap Bolts. Pull Handle Insert Adjustable Pins Into both side panels and Middle Panels at the desired level. Slide Shelf (G) into place. Assemble Pull Handle to Door (P) and (Q) with Machine Screws.
