88 5001
Buffet and Hutch
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Hutch Unit Part List
A.
Top
1 pc.
F.
Back Stretcher
1 pc.
G.
Back Stretcher
1 pc.
I.
Fixed Shelf
1 pc.
Cam Lock
14 pcs.(+1 extra)
Cam Lock Screw
14 pcs.(+1 extra)
Tools Required For Assembly : Phillips screwdriver
B.
Side Panel
1 pc.
H.
Front Piece
1 pc.
J.
Shelf
1 pc.
Adjustable Pin
4 pcs.(+1 extra)
Wood Screw
for Back Panel
8 pcs. (1 extra)
Hutch Unit
Casual Attire For Today's Home
C.
Side Panel
1 pc.
Machine Screw
2 pcs.
Wood Screw
for Steel Plate
Connector
8 pcs. (1 extra)
D.
E.
Back Panel
Back Piece
2 pcs.
1 pc.
K.
L.
Door
Door
1 pc.
1 pc.
Door
Steel Plate
Pull Handle
Connector
2 pcs.
2 pcs.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Styles KF868
Summary of Contents for Home Styles KF868
- Page 1 88 5001 Buffet and Hutch IMPORTANT NOTE Hutch Unit Carefully remove all the parts from the carton and put them individually on a soft cloth to prevent scratches or other damages occuring to the wood parts. We have taken great care in the design of this product and request that you carefully and strictly follow our assembly instructions to ensure a completed product as it was designed.
- Page 2 Assembly Instructions 2/3 Cam Lock Screw STEP 1 Insert Cam Lock Screws into the pre-drilled holes at Side Panel (B) and (C) and tighten up. Attach Back Piece (E) in between Back Stretcher (F) and (G). Slide Back Panel (D) into place. Attach Side Panel (C) to the unit with Cam Locks.
- Page 3 Assembly Instructions 3/3 STEP 4 Insert Wood Screws from the back and tighten up. STEP 5 Place the Hutch unit onto the Buffet unit. To hold firmly the Hutch and Buffet, attach Steel Plate Connectors, insert Wood Screws and tighten up. (See figure 4) Wood Screw Steel Plate...
- Page 4 Attention ! For safety reasons, we recommended you strictly follow this additional instructions as to prevent this Buffet & Hutch Unit from tipping over. HARDWARE LIST Plastic Belt 2 pcs.(+1 extra) Wall Screw (long) 2 pcs.(+1 extra) Wood Screw (short) Steel Bracket Anchor (A) Anchor (B)
