Buffet
IMPORTANT NOTE
.
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure
a completed product as it was designed.
Part List
A.
B.
Side Panel
Side Panel
1 Pc.
1 Pc.
I.
Back Stretcher
1 Pc.
M.
Shelf
1 Pc.
Hardware List
Hex Wrench
1 pc.
M6x50
Head Cap Bolt (long)
Small Hex Wrench
4 Pcs. (+1 extra)
1 Pc.
Tools required for assembly : Phillips screwdriver, Drill, 3/8" Drill Bit Level
Home Styles Consumer Assistance : www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
C.
Front Stretcher
1 Pc.
D.
Front Stretcher
1 Pc.
J.
Back Panel
2 Pcs.
M6x35
Cam Lock
Head Cap Bolt
10 Pcs. (+2 extra)
4 Pcs. (+1 extra)
Cross Dowel
4 Pcs. (+1 extra)
E.
Front Upright
1 Pc.
F.
Back Stretcher
1 Pc.
N.
O.
Door
Door
1 Pc.
1 Pc.
M3.5x13
Cam Lock Screw
Wood Screw (short)
10 Pcs. (+1 extra)
for Base Drawer
8 Pcs. (+1 extra)
M3.5x25
Wood Screw (long)
Adjustable Pin
for Side Drawer
4 Pcs. (+2 extra)
16 Pcs. (+1 extra)
,
G.
Divider
1 Pc.
H.
K.
Back Upright
Base
1 Pc.
1 Pc.
L.
Leg
2 Pcs.
P .
Drawer
2 Pcs.
(Please refer to the last page of these
instructions for drawer assembly steps.)
M4x25
Machine Screw
6 Pcs.
M3.5x16
Pull Handle
Wood Screw
2 Pcs.
for Back Panel
8 Pcs. (+1 extra)
Knob
2 Pcs.
