Instruction manual for CoolSafe
6.3.1

Programme list

Touch screen – as opened
6.3.2

Start

Touch screen – as opened

6.3.2.1 Current shelf temperature

Touch screen – as opened
01012016QA01
Item
Item
Freeze drying time
Ice condenser temp.
Actual pressure
Actual shelf temp
Product temp.
Set-point shelf temp
Set-point pressure
Alarm pressure
Reset Error
Item
Item No. 700636
CopyRight © 2016
Action
List of programmes 1 to 10. Press the
desired programme to activate.
Press the LaboGene logo to return to the
auto menu.
Press the LaboGene log for 2-3 seconds
to lock the display for input. Unlock press
again.
Action
The time period the freeze dryer has run
the current programme.
View the current ice condenser
temperature.
View the current pressure in the ice
condenser.
Press to see list of Current shelf
temperatures.
View the current product temperature.
View the shelf temperature set-point
View the current ice condenser pressure
set-point.
Press to set the alarm pressure.
Press to reset counter.
Press the LaboGene logo to return to the
main menu.
Press the LaboGene log for 2-3 seconds
to lock the display for input. Unlock press
again.
Action
Press the LaboGene logo to return to the
auto menu.
Press the LaboGene log for 2-3 seconds
to lock the display for input. Unlock press
again.
Page 15 of 35
