5.2.4.1 Turnpoints

Turnpoint files, in the .cup file format, are not supplied by LX navigation, but can usually be
found at competitions, various webpages or from club manager and club mates. As a starting
point, you can check the Open flight maps. You can even create your own turnpoint files
either by hand, or using different software.
In order to use turnpoint files on your LX Traffic Square, first you need to copy them to the
device. In order to do this, you need to have the file saved to the root of your microSD
card. Once the microSD card is inserted go to Load sub-menu and select the file you wish to
transfer to the LX Traffic Square's internal memory.
Now go to the Select sub-menu and select which of the files in the LX Traffic Square's internal
memory you wish to have active.
You can have multiple turnpoint files active at the same time.
The LX Traffic Square requires turnpoints in the .cup file format.

5.2.4.2 Airports

Airport files, in the .af file format, are supplied by LX navigation exclusively. For the latest
available database files, check the Database part of LX webpage.
The airports file holds the frequencies to all airports, which is why it is especially important to
use the latest database files available. If inconsistencies are found in the files, please refer
them to the LX navigation support email.
In order to use a certain airport file, first you need to copy it to the LX Traffic Square's
internal memory, through the Load sub-menu, and then select it as active through the Select
sub-menu. Only one airports file can be active at a time.
The LX Traffic Square requires airport files in the .af file format.
