LX Traffic Square
Basic operation
AUDIO-OUT adapter cable - for connecting to a speaker or intercom
Please note that the device can only be used in landscape mode.
We will name the different movements of the 4-way push button by their functions:
LEFT-RIGHT - Pages - Changes between pages
UP-DOWN - Zoom - zooms on zoomable pages
Short press - Enter - enters page, text dialog, confirm etc
Long press - Sub-page - opens additional sub-page on pages that have them (mainly
navigation pages for additional info for navigation points)

3.3 User input

The 4-way push-button's operation can be divided into left-right and up-down motion with ap-
propriate short and long-press functions.

3.3.1 Left-right motion

Left-right motion is used for the following functions:
Changing between primary pages

3.3.2 Up-down motion

Up-down motion is used for the following functions:
Zooming, on all zoomable pages
Scrolling through menus and choosing letters and number in alphanumeric dialogues

3.3.3 Short-press

Short-pressing (1s) the push-button will act as 'enter', 'confirm', 'yes', 'open', etc.

3.3.4 Long-press

Long-pressing (3s) the push-button will act as 'open sub-page', 'exit', 'back'. The latter two
only when in a sub-page.

3.3.5 Really long-press

Really long-pressing (10s) the push-button will perform a hard-reset of the device.
