LX Traffic Square
Advanced operation
Entering the Logbook page will show the list of all flights the LX Traffic Square has in its
memory. You can move up-down the list with the up-down movement of the push-button.

4.4.2 Flight statistics

Once the device enters flight mode, the Flight statistics page appears.
We can see the take-off time, flight duration, maximum altitude and maximum indicated
airspeed, as well as an altitude graph.
Once the LX Traffic Square determines that you are not in flight, it will start the 5
GPS lock
Ground speed less than 10 m/s
Altitude less than 3000 m QNH
If you wish to forcefully finish a flight, prior to the LX Traffic Square starting the
finish procedure, you can do this by going to the 'Flight statistics' page and
pressing the push-knob and confirming the 'End flight?' question.
If the LX Traffic Square turns off due to the external power supply being cut,
Device manual
Figure 17. Logbook page
NOTE
minute countdown to finishing your flight.
The conditions for finishing a flight are:
NOTE
WARNING
the flight might not be logged.
