LX Traffic Square

Basic operation

We will go through the basic gestures and what they do on all pages of the LX Traffic Square
system.
The Traffic Square uses a single 4-way push button with both short and long-press functions.
3.1 Turning the LX Traffic Square on
The LX Traffic Square is turned on automatically when power is supplied to the Flarm port,
meaning it does not have a turn-on and shut-down option.
Once the device is turned on, a sequence of screens will appear in the following order:
LX navigation greeting screen
Second screen stating the device type, serial number and firmware version
When the device is turning on, a warning may appear, indicating limited operation
capability to the pilot. You should contact LX support as soon as possible. The
device might be operable even with the warning present, but full operational
Internal memory error - there is an issue with the internal memory of the
device. Device will continue to operate and show Flarm warnings, but some
pictures and assets may be corrupted.
Device manual
Basic operation
WARNING
capability is not guaranteed.
