1.8.2 Operation

Be sure the actuator is correctly mounted as indicated in the user instructions.

Be sure the equipment can be moved easily over the actuator's whole working area.

Be sure the actuator is connected to a main electricity supply/transformer with the correct voltage,

specified on the actuator label.
Be sure that the connection bolts are secured safely and can withstand the wear.

Stop the actuator immediately if anything unusual is observed.

Ensure there is no side load present on the actuator.

Only use the actuator within the specified working limits.

Refrain from having any contact with the actuator.


1.8.3 Equipment power off

Switch off the main supply to prevent any unintentional operation.

Regularly check for extraordinary wear.


1.8.4 Duty cycle

The standard duty cycle is 25%.

If the product is customized, please refer to the approval drawings.


1.8.5 Temperature

The operating temperature range is -30°C ~+65°C.

The operational temperature range at full performance is +5°C ~+45°C.

