9.4.2 Setup Menu
This section describes each item on the setup menu. Use this menu to configure the power controller for the
load. The password to access this menu is 2.
Parameter Name
Out Scale
Set the percentage by which the set point
is scaled. For example, if a 0 to 10V analog
input providing the set point is 5V and output
scaling is 80% then the effective set point is
40%
Parameter Name
I Limit SP
Set the maximum percent of the
nominal current that the power control
allows. This parameter indicates RMS
current by default.
When parameter 52 is set to 1, this
parameter indicates peak current
Nom Line V
Set the nominal value for the line
voltage input
Nominal I
Set the nominal load current
Soft Start
Set the duration of the soft start in
increment of 100mSec. The power
controller ramps set to point changes
over the time set here. For more
information see "Firing type" page:
Soft Start with Burst Firing and Soft
Start with Phase Angle
SP select
Choose the source for the remote
set point
Description
100
80
60
40
20
0
0 20 40 60
Input
Description
Option Value
Analog In 1
Analog In 2
80 100
Default
100%
220V
Maximum
current
100
(10 sec)
0
0
1
29
User's manual
Modbus
Range Unit
Address
0 to 100.0 %
Modbus
Range Unit
Address
0 to 100.0 %
0 to 1023 V
0 to 999.9 A
0 to 255
(0 to 25,5
sec)
Par.
Type
Read
16
Write
Par.
Type
Read
17
Write
Read
37
Write
Read
38
Write
Read
23
Write
Read
61
Write
