CD Automation REVEX 1PH 280A User Manual page 34

REVEX
1PH 280A
Parameter Name
DI1 Functn
Option
Enable
Enable power output
V Feedback
Use voltage feed-back when on
Local / Rmt
Local when on / Remote when off
Ph Angle
Use phase angle firing when on
SP AI1/AI2
Select remote set point source: analog input 1 when off or analog input 2 when on
Htr Bake
Enable heater bakeout
FastEn
Fast Enable
DEFAULT: Voltage Feed-back
SSR Input: 4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc) 3HZ Max on time min. 100 ms
Parameter Name
DI2 Functn
Option
Enable
Enable power output
V Feedback
Use voltage feed-back when on
Local / Rmt
Local when on / Remote when off
Ph Angle
Use phase angle firing when on
SP AI1/AI2
Select remote set point source: analog input 1 when off or analog input 2 when on
Htr Bake
Enable heater bakeout
FastEn
Fast Enable
DEFAULT: Enable
SSR Input: 4 ÷ 30Vdc 5mA Max (ON >4Vdc OFF <1Vdc) 3HZ Max on time min. 100 ms
Description
Choose how the signal detected by digital input 1
is used
Description
Choose how the signal detected by digital input 2
is used
Description
Description
34
User's manual
Modbus
Default
Address
2 32
Modbus
Default
Address
0 33
Par.
Type
Read
Write
Value
0
2
3
4
5
7
8
2
Par.
Type
Read
Write
Value
0
2
3
4
5
7
8
0
