- Page 1 OPERATION MANUAL Laminate Cutter PL-215 www.dcutproducts.com CUTTING AND C...
- Page 2 Assembly Use the provided Allan wrench, screws, bolt and nuts to assemble the blade into the base and handle as shown. Warning: Avoid contacting with the steel teeth along the cutting slot, which may cause injury. Carry Hook the chain to the ring on the handle and carry the cutter as shown.
- Page 3 The Slot on the Cutter Base On the cutter base, there are a few sets of the slot used for the stopper attachment. Always use the slots closer to the pivot of the blade according to the width of the plank. The closer to the pivot of the blade, the more cutting power you will get.
- Page 4 Free Angle Cut Mark a line of the floor plank and remove the stopper attachment from the cutter base. Line up the blade with the line marked on the plank, then push down the blade by using the handle. The small teeth located along the cutting slot will keep the laminate plank from slipping.
- Page 5 P a r t L i s t...
- Page 6 P a r t L i s t Parts Q’ty Parts Q’ty Left ABS Handle Supporting Bar C Cross Head Screw M4 × 31 Right Steel Teeth Handle Right Working Table Knurled Screw M5 Supporting Bar B Rubber Pad End Plate Blade Stopper Attachment Spring Pin...
