Fancom 743

2. Technical specifications

Power supply
Mains voltage
Mains frequency
Maximum power consumption
Available power supply for sensors and equipment
24Vdc (fused)
12Vdc, short circuit resistant
13 Relay outputs
Relay 1-12, voltage free*
Relay 13 (alarm relay, voltage free)
10 Analog outputs (8 bits)
Voltage range
Maximum load
Output resistance
8 Contact inputs
Open contact voltage (high level)
Low level
Application: Counter input, min. pulse width 2.5mSec
frequency input
1 Weigher input, resolution 12 bits (not for commercial purposes)
Excitation
Max. input voltage
Max. load
Max. cable length
Housing
Plastic housing with screw on lid
Dimensions (l×w×h)
Weight (unpacked)
Ambient climate
Operating temperature range
Storage temperature range
Relative humidity
Communication
FNet, Fancom network, for intercommunication of control computers and PC connection*.
Optional: Fancom serial loop for intercommunication of control computers and PC connection*
I/O-Net for extra in and outputs using I/O-modules; max. 30 IDM and/or IRM-modules, each with 16
in/outputs*.
- max pulse frequency IDM input:
- max. pulse frequency IRM output:
* For electrical connection and/or cable data, see connection diagrams.
INSTALLER: 2. Technical specifications
max. 2A 60Vdc/30Vac or max. 2A 250Vac
300×360×140mm/11.8×14.2×5.5ins.
0°C to +40°C/32°F to 104°F
-10°C to 50°C/14°F to 122°F
2
230Vac (-10% +6%)
50-60Hz
50VA
max. 500mA
max. 150mA
max. 2A 60Vdc/30Vac
0-10Vdc
1mA
570Ω
12Vdc
<1.5Vdc
max. frequency 200Hz
max. frequency 5kHz
10Vdc
20 mVdc
2 × 350Ω weighing bar
40 m
IP54
3.9kg/8.6lbs
< 95%, uncondensed
25/sec.
0.5/sec.
