Fancom 743
Counts
The weighing bar signal (rough measurement).
Zero/Offset
A calculated value corresponding to the zero setting of the ILM.x/weigher
combination.
Span (Cal.)
A calculated value corresponding to the calibrated ILM.x/weigher combination.

Filter The number of measurements (maximum 25), used by the computer to
determine an average stable weight.
Stable The difference (accurate to the gram) between the highest and lowest
measurement used by the computer to determine a stable weight.
Enter whether there is a hopper.
Hopper
Max. sensor
Enter the address (in front of the point) and the digital input number (behind
the point) to which the maximum sensor has been connected.
Min. sensor
Enter the address (in front of the point) and the digital input number (behind
the point) to which the minimum sensor has been connected.
Empty hopper
Enter within how much time (minutes and seconds) the hopper should be empty
(min. sensor free)
Mixer relay
Enter the address (in front of the point) and the relay number (behind the point)
to which the mixer has been connected.
Status
Status shows whether the mixer is active (ON) or not (OFF).
Wait time dec.
Enter within how many minutes and seconds the weigher content must
decrease after dosing out has started.
Min.dec./30sec
Enter the minimum weigher content (kg) decrease each 30 seconds during blend
dosing out.
Empty weigher
Enter within how much time (minutes and seconds) the weigher should be
empty after the unloading valve has been opened.
Block during TR
Enter if feed may be prepared when there is feed on transport.
Simulation
YES
NO
The following settings are important if

Increase
Enter the weight increase for simulation mode.
Decrease
Enter the weight decrease for simulation mode.
Status
Status of the weigher content in simulation mode: INCREASE or DECREASE.
The computer uses the values of
Counts
weighing bar signal
If the empty weight changes, because a lid has been added for example, the
zero point must be re-adjusted. If the weighing bars and/or ILM.x are
changed, repeat zero setting and calibration.
Simulation mode
Normal mode
Simulation
INSTALLER: 5. System settings
Span
and
to calculate the actual weigher weight (
is set to YES.
11
Zero/Offset
and the rough
Weight
).
