CCTR-821 Mini Car GPS Tracker Using Guide
Welcome to use this Real Time mini GPS tracker CCTR-821, This product is with GPS module and
GSM module, It is mini design for cars, truck, bus, rent vehicle, etc. it has wide working voltage (9-40V),
so it can suit for the 12V or 24V vehicle, it can upload current location to website, display history tracking
on website, also it has Google map link locate function without platform, also it built in shock sensor to
control power saving, shock & move alarm, over area alarm, over speed alarm, etc.
User visit the website
through any computer with available internet, and without downloaded any software. And it can help to
arrange the whole fleet or the vehicles of company or group or personal vehicles with the anti-hijack
function.
And also user can download Android app software to android mobile phone, click the app, logon with
user name and password, you can locate current location & display history tracking, the user name and
password is same with the website login. Using mobile phone
locate current location, Send SMS or call the tracker, the tracker will send back the current location
Google map link by SMS.
This GPS tracker can be used as car alarm, fleet management, driver management etc, it can be
used for tracking cars, company vehicles, buses, taxis, trucks, moving equipments, transportations, etc.
iPhone App Download QR Code
Manual(Word) Download QR Code
www.999gps.net
with the applied user's name and password (Given by us)
visit
http://wap.999gps.net
Android App Download QR Code
Manual(Pdf) Download QR Code
also can

Advertisement

Table of Contents
loading

Related Manuals for Carscop CCTR-821

Summary of Contents for Carscop CCTR-821

  • Page 1 CCTR-821 Mini Car GPS Tracker Using Guide Welcome to use this Real Time mini GPS tracker CCTR-821, This product is with GPS module and GSM module, It is mini design for cars, truck, bus, rent vehicle, etc. it has wide working voltage (9-40V),...

  • Page 2: Packing List

    Packing list Connect 9-V Power RED: VCC (Battery + ) BLACK: GND or Car Body This Side face to sky Please don’t face to ground CCTR-821 Specification  Universal 4 GSM Band for Global;  Wide Range Working Voltage: 9-40V DC;...

  • Page 3: How To Install

    Note: 1. This tracker use 2G GSM network, and it upload tracking only through GPRS, it can not work in CDMA network or 3G(WCDMA or CDMA2000) network. (Some 3G SIM card can use in 2G GSM network, this kind of 3G SIM card can use in this tracker) 2.

  • Page 4: How To Use

    2. Installation Place on the vehicle The tracker should be installed in the hidden place, then it is not easy to be broken and removed, because the GPS & GSM antenna are built in the tracker, so you should confirm the installation place have good GPS and GSM signal, the GPS antenna should face to sky, and it can not face to ground, please keep the tracker away from the big metal, we recommend install the tracker under the front panel of the car, or under the rear panel or under the rear glass, or in the pillar...
  • Page 5 phone. This means the GPS and GSM is working. 4. Upload the tracking to internet server through GPRS also you need set APN etc, send SMS to tracker to set the tracker SIM card APN / GPRS user name & password / Plmn number etc. apn,xxx# apn,xxx,plmn,yyy# apn,xxx,user,uuu,pd,ppp,plmn,yyy#...

  • Page 6: Command Instruction

    Command Instruction Only center or slave center number can send SMS to control or change the setting of the the tracker, the alarm SMS will send to center and slave center number, but the alarm calling only call to center number, so please send SMS to tracker to set the center or slave center number first.
  • Page 7 has no reply, please check the tracker work properly and confirm the SMS command is right. 5. Delete center and slave center number. Send SMS “pw,123456,center,d#” to the tracker to delete center number, and Send SMS “pw,123456,slave,d#” to the tracker to delete slave center number,123456 is the tracker default password, the tracker will reply delete center or slave number OK.
  • Page 8 9. Set tracker sleep out time Send SMS “sleepout,0#” (time unit is minutes, from 0-1800, 0 means no sleepout) to the tracker to set the sleepout time, after set sleepout time, the tracker will back to online every interval time and sleep again, this can keep the tracker update the location every interval time.

  • Page 9: Troubleshooting

    work in CDMA network or 3G(WCDMA or CDMA2000) network, if the 3G SIM card can use in 2G GSM network, then the SIM card can be used in this tracker. The antenna of GSM and GPS is built in tracker, please note that the install location of the tracker must can receive the GPS signal, normally the back of the seat or arm rest box or under the back window or room on the panel etc.

  • Page 10: Warranty

    User Mobile Phone Tracker SIM card Date Year month Model CCTR-821 Serial Number Distributor Notes: The explanation of this manual is belonged to our company, some small changes may not notice customer, if you have any problem please contact us, thanks !
