Diagnostic - TP-Link WR841HPV5 User Manual

Chapter 4
¾ To set Daylight Saving Time:
1. Select Enable DaylightSaving.
2. Select the start time from the drop-down list in the
3. Select the end time from the drop-down list in the
4. Click Save.
Note:
This setting will be used for some time-based functions such as firewall. You must specify your time zone once you log
in to the router successfully; otherwise, time-based functions will not take effect.

4. 16. 3. Diagnostic

Diagnostic is used to test the connectivity between the router and the host or other
network devices.
1. Visit http://tplinkwifi.net, and log in with the default username and password: admin.
2. Go to System Tools
• Diagnostic Tool - Select one diagnostic tool.
• Ping - This diagnostic tool troubleshoots connectivity, reachability, and name
resolution to a given host or gateway.
• Tracerouter - This diagnostic tool tests the performance of a connection.
Note:
You can use ping/traceroute to test both numeric IP address or domain name. If pinging/tracerouting the IP address is
successful, but pinging/tracerouting the domain name is not, you might have a name resolution problem. In this case,
ensure that the domain name you are specifying can be resolved by using Domain Name System (DNS) queries.
• IP Address/Domain Name
Domain name (such as www.tp-link.com).
> Diagnostic.
- Enter the destination IP address (such as 192.168.0.1) or
Configure the Router in Standard Wireless Router
Start field.
End field.
66
