MAIN PARTS LIST Bottom divider panel Middle shelf Left panel Right panel Bottom back panel Bottom panel Top divider panel Top back panel Door Top main panel MAIN PARTS LAYOUT ( FOR REFERENCE ):...
SCREWS LIST: Screw Screw ☛ This unit uses cam bolts and locks. The following explains how to use them. This is not an assembly step; it is a guide for when you are actually doing the assembly using this kind of hardware. Cam Lock Cam Bolt 1.
Page 5
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS. ❼ ❶ To avoid misalignments, Do a quick inventory to always leave the screws loose make sure the package contains and tighten them until all all the parts and hardware listed pieces are positioned correctly.
ASSEMBLY STEPS Insert the wooden pins ( 1 ) into panels ( A - B - C - D - F ) as shown. STEP 1 Hardware: ATTENTION: Make sure to insert the Wooden Pin in the correct holes, as some other holes are intended for the cam bolt!.
Page 7
STEP Remove the top caps from the Plastic Feet ( 8 ) and assemble the to bottom panel ( E ) using screws ( 3 ) as shown. Hardware: STEP Attach the magnets ( 9 ) to the bottom panel ( E ) with the magnets facing to the front as shown, and save their screws to use in step number 8.
Page 8
Assemble panel ( A ) to panel ( E ) as shown and secure with screws ( 4 ). STEP Hardware: STEP Join the middle panel ( B ) to panel ( A ) ( no screws are needed here ). ☛...
Page 9
Attach the screws from the magnet set ( 9 ) to both door panels ( I ), then place both STEP metal pins ( 6 ) as shown. Hardware: Place the door ( I ) on the left side in between panels ( A ) and ( C ), then secure the panel ( C ) using STEP screws ( 4 ) as shown.
Page 10
Place the door ( I ) on the right side in between panels ( A ) and ( D ), then secure the panel STEP 1 ( D ) using screws ( 4 ) as shown. Hardware: 2 PERSONS REQUIRED STEP Attach Cam Bolt ( 2 ) to Top Main panel ( H ) as shown.
Page 11
STEP Attach panels ( F ) to panel ( B ) as shown Insert the Cam Locks ( 2 ) into the holes of panels ( C ), ( D ) and ( F ) and align them as STEP it is explained on page 4.
Page 12
Assemble the back panels ( G ) and ( J ) with their finished surfaces facing towards the STEP inside of the stand, using Nails ( 5 ) as shown. The plain surfaces will face the outside. Hardware: ( Plain surface facing outside )
Page 13
AFTER THE ASSEMBLY IS DONE, PLEASE READ CAREFULLY THE FOLLOWING WARNINGS FOR CARE AND MAINTENANCE: STORAGE A STORAGE B Do not exceed the indicated weight limits. Do not expose the surfaces to direct sunlight or to extreme environmental conditions. Damages caused by this kind of exposure is not covered by the product's warranty.
