- Page 1 Pneumatic Arm Dual Monitor Desk Mount Instruction Manual SKU: STAND-V002JB Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v002jb help@vivo-us.com www.vivo-us.com 309-278-5303...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 17.6 lbs Failure to do so may result in serious injury. (8 kg) PER ARM Phillips Screwdriver ASSEMBLY STEPS STEP 1 Adjust clamp (A) to fit desktop. Make sure pole is secured in base by twisting clockwise, then use 3mm allen wrench (G) to tighten grub screw in back of base.
- Page 4 STEP 3 Adjust the locating ring to desired height and tighten to support the arms. Adjust the aluminum support bracket to rest on the locating ring and secure using handle and the 3mm allen wrench (G). S=3mm STEP 4 Place the extension arms (C) onto the aluminum support bracket and secure each one using bolts (K) and plastic cap (L).
- Page 5 STEP 5 OPTION A: Flat Back Monitor Attach VESA plate of arm (B) to back of monitor using four screws (D, E) as shown in diagram. OPTION B: Curved Back Monitor For recessed monitors, spacers (I) and screws (F) may be required.
- Page 6 STEP 6 Attach arms (B) to extension arms (C) using bolts (K) and plastic cap (L) using a phillips head screwdriver as shown in diagram. STEP 7 Use the 5mm allen wrench (H) to adjust the spring tension inside the arms (B) as shown in diagram, depending on the weight of your monitors.
- Page 7 STEP 8 Use the 3mm allen wrench (G) to adjust tension in arms, and the 5mm allen wrench (H) to adjust tension in monitor brackets. S=3mm S=5mm S=3mm STEP 9 Insert monitor cables into cable covers on underside of arms (B). Leave enough slack to allow full adjustment and motion of arms.
- Page 8 - 83% within < 2hr - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
