Mechanical Arm Dual Monitor Desk Mount
Instruction Manual
SKU: STAND-V002O
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v002o
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-V002O and is the answer not in the manual?

Questions and answers

Related Manuals for Vivo STAND-V002O

Summary of Contents for Vivo STAND-V002O

  • Page 1 Mechanical Arm Dual Monitor Desk Mount Instruction Manual SKU: STAND-V002O Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v002o GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...

  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.

  • Page 3: Assembly Steps

    ASSEMBLY STEPS STEP 1 (Option A) Clamp Installation Remove plastic shroud from Base (C). Adjust the knob completely down on Lower Clamp (F). For 0.4”-1.90” (10-50mm) desktops install Upper Clamp (E) to Base (C) using M6x8mm Screws (S-A) and 5mm Allen Wrench (T-B). Reinstall the plastic shroud onto Base (C). Attach Lower Clamp (F) to the top two holes on Upper Clamp (E) using M6x10mm Screws (S-B) and 4mm Allen Wrench (T-A).
  • Page 4 STEP 1 (Option B) Grommet Installation Mark two drilling locations 2” (51mm) apart in desired location. Drill grommet holes using a ⅜” (10mm) drill bit drilling completely through the desktop. Disassemble Lower Clamp (F) using the Phillips end on 5mm Allen Wrench (T-B). Place Grommet Plate (G) on Knobs (F1,H) and secure assembly to the desktop.
  • Page 5 STEP 3 Attach VESA Plates (D) to Upper Arms (B) using M8x30mm Screws (S-C) and 5mm Allen Wrench (T-B). STEP 4 Install two Screws (M-A or M-B) and M5 Washers (M-C) using the Phillips end on 5mm Allen Wrench (T-B) to the top VESA holes on the monitor leaving at least 3mm of clearance between the screw and monitor.
  • Page 6 STEP 5 Tighten the top two screws and install the remaining Screws (M-A or M-B) and 5mm Washers (M-C) using the Phillips end on 5mm Allen Wrench (T-B). STEP 6...
  • Page 7 STEP 7 Remove bottom plastic covers from Lower Arm (A) using the Phillips end of 5mm Allen Wrench (T-B). Slide plasic covers off of Upper Arms (B). Run cables from monitors through bottom of Upper Arms (A) and Lower Arms (B), then reattach plastic covers. STEP 5 Adjust monitor tilt support using 5mm Allen Wrench (T-B) as shown.
  • Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
