Pneumatic Arm Dual Monitor Desk Mount
Instruction Manual
SKU: STAND-V002K
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v002k
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAND-V002K and is the answer not in the manual?

Questions and answers

Related Manuals for Vivo STAND-V002K

Summary of Contents for Vivo STAND-V002K

  • Page 1 Pneumatic Arm Dual Monitor Desk Mount Instruction Manual SKU: STAND-V002K Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v002k GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 2.2-17.6lbs Failure to do so may result in serious injury. (1-8kg) PER ARM Phillips Screwdriver ASSEMBLY STEPS STEP 1 OPTION A: Clamp Installation Adjust clamp (B) height according to thickness of desktop. Attach clamp cover (C) to clamp (B). Secure pole (E) to clamp (B) using three bolts (H).
  • Page 4 STEP 1 (Continued) OPTION B: Grommet Base Installation For grommet hole attachment, disassemble clamp (B) using 6mm Allen key (L) and a Phillips screwdriver. Attach base (J) to pole (E) through ⅜” (10mm) grommet hole in desktop. Secure using bolt from clamp (B) and plate (I). STEP 2 Slide cable management clip (F) over top of pole (E).
  • Page 5 STEP 3 Adjust arm (A) to desired height. Tighten using 6mm Allen key (L). STEP 4 Attach VESA plate (D) to the back on monitor using bolts (M-A, M-B, M-C, M-D) and washers (M-E). For curved monitors, spacer (M-F) may be required. M- A M- C M- E...
  • Page 6 STEP 5 Slide VESA plate (D) over bracket on arm (A). Secure using thumb screw (G). Remove bottom covers from arm (A). STEP 6 Run cables through bottom of arm (A). Re-attach covers.
  • Page 7 STEP 7 Adjust tension in arm and angle of monitor using 6mm Allen key (L). Clockwise reduces tension, counterclockwise increases tension. The tension should be just enough to hold your monitor in place without lifting itself up.
