SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com | Phone: 818-991-1778 | Fax: 866-293-6751
WARRANTY INFORMATION:
All SSV Works enclosures are covered by a limited lifetime warranty against defects in
material or workmanship. All SSV Works Electronics are covered by a limited 1 year warranty
against defects in material or workmanship. All SSV Works Speakers are covered by a
limited 1 year warranty against defects in material or workmanship. Labor for replacement of
defective components is not covered. Contact SSV Works for further warranty information.
TOOLS NEEDED FOR INSTALLATION
- Utility Knife
- 10mm Socket with Extension
- Drill with 1/8" and ¼" Drill bit
PARTS LIST IMAGES
1. CM2-UD10-U
Enclosure x 1
5. M6 Locking Hex Nut x 1
- Wrench for Battery Terminal
- #3 Phillips Screwdriver
- T-30 Torx Driver
4. M6 x 16mm Screw x 4
6. Bottom Mounting
Bracket x 1
Commander and Maverick
Under Dash Subwoofer Enclosure
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
3. M6 Washers x 5
CM2-UDSB10 DRILL TEMPLATE
FOLD THIS TAB UP ON DOTTED LINE
SSV WORKS INC. CM2-UDSB10 DRILL TEMPLATE REV. A, 5/5/2017
7. Drill Template
CM2-UD10
