Stylistic St4000P Hardware Specifications - Fujitsu Stylistic 4110P User Manual

Stylistic ST4000P Series Hardware Specifications
The following table provides general hardware
specifications of the Stylistic ST4000P Series pen tablet
PC by category.
Stylistic ST4000P Specifications
Physical Specifications
Dimensions 11.86" w x 8.66" d x 0.82"-0.88" h
(301.3mm x 220mm x 20.9-22.3mm)
Weight 3.2 lbs. (1.45 Kg)
Processing Specifications
CPU Ultra low voltage Mobile Intel Pentium
III processor - M with SpeedStep
technology*
Chip set Intel 830MG - 133 MHz
Processor 800 MHz*
Speed
Memory/Storage Specifications
Main RAM • 256MB SDRAM (on-board/
PC133).
• 144-pin SO DIMM modules
256MB and 512MB module
configurations available, with a system
maximum of 768MB.
L1 cache 32 KB on-die
(CPU)
L2 cache 512 KB on-die
8 Mbit (FWH)
BIOS ROM
Hard disk • 2.5" HDD
drive
• Minimum 20GB IDE HDD*
• Ultra DMA 100
• Shock-mounted
S y s t e m S p e c i f i c a t i o n s
Stylistic ST4000P Specifications (Continued)
Display
3
3
VRAM
3
PC Card
Slots
Integrated
Interfaces
Infrared
Display Specifications
• Color LCD
• Passive Touch Panel
• 16-bit color
• 10.4" TFT XGA (1024 x 768), 260K
colors
• Brightness: 8 levels
• Viewing Angle:
Horizontal: 30 degrees (min.)
Vertical: 10 degrees (min.)
• Contrast Ratio:
Typ. 250, Min. 100
Intel 830MG chipset with 8MB shared
memory using Unified Memory
Architecture (UMA) delivers low-
power, high-performance 3D/2D
graphics, video, and display capabilities.
Dynamic Video Memory Technology
(DVMT) dynamically responds to
application requirements and efficiently
allocates the proper amount of memory
(48MB max.) for optimal graphics and
system performance.
Interface Specifications
• One Type I or Type II
• PCMCIA CardBus version 3.0
• Modem (RJ-11)
• LAN (RJ-45)
• IEEE 1394 (S400 4-pin)
• USB (Qty. 2)
• DC-In
• 15-pin D-SUB connector for
external VGA monitor
• Docking connector
IrDA version 1.1 (FIR, 4Mbps)
3
3
35
