APPLICATION BUTTONS

The six application buttons are located on the upper
right-hand side of a vertically-oriented system. (See
figure 1-2 on page 3 for location). Three of the buttons
have secondary functions. The secondary functions are
activated by pressing the Function (Fn) button while
pressing the application button.
The buttons also have separate tertiary functions that
can be used while the system is booting up. For more
Tablet Icon
Button Icon (Fn +
and Name Button)
(Primary) (Secondary)
Ctl-Alt-Del
Button
Hovering
Right-Click
Mode
Button
Orientation
Button
Escape
Application
Button
A Button
10
The Ctl-Alt-Del button performs two functions:
• Pressing the Ctl-Alt-Del button for up to one second allows you to log on
after boot, after locking the workstation, or after resuming from power
management
• After log-on, pressing the Ctl-Alt-Del button for up to one second launches
the Windows Task Manager.
When you press the Right-click button, your pen switches its function from left
mouse button to right mouse button emulation. To generate a right mouse button
click, tap on the application button once and then tap on the display.
When you press the Fn + Right-click buttons at the same time, they provide a
Hovering function. Hovering mode provides you with better cursor control. When
hovering is enabled, the cursor can be positioned over an area of the screen
without activating it. This is useful when you are attempting to read pop-up text
associated with an icon, simulating mouse rollover, selecting a small icon, or
beginning a paint session. Note that when Hovering Mode is active, the Hovering
Mode Status Display LED is lit (see Table 1-2). Pressing the Fn + Right-click
buttons at the same time again exits the Hovering function
When you press the Orientation button, the system screen orientation changes
from portrait (vertical) to landscape (horizontal) or from landscape to portrait.
When you would like to use the tablet as an eBook, for example, you would use
the portrait orientation, when accessing spreadsheets, you would more typically
use a landscape orientation.
The Escape application button acts the same way as an Escape key on a keyboard.
When you press the Fn + Esc buttons at the same time*, they act to invoke a pre-
determined application or generate a combination keystroke, as assigned the
Tablet Button Settings utility. (You can change the settings in Control Panel ->
Tablet Button Settings).
By default, pressing the Fn + Esc combination acts the same as if you had pressed
Ctl + Esc on a keyboard: the Start menu is launched.
information about the tertiary functions, refer to
Table 1-5 on page 13.
P O I N T
Ctl-Alt-Del is the only Application button that can be
used while the system is logging on or when the system
is locked (i.e., when you have the Logon or Computer
Locked window showing on your desktop).
Description
