STATUS DISPLAY

Icons appear in the Status display indicating the status of
system functions such as system power and battery
charge level. The location of icons in the Status display is
shown in Figure 1-7.
Table 1-2 explains how individual icons are displayed,
and describes what the variations of that display indi-
cate. (If an icon is not displayed, it indicates that the
related system function is off or inactive.
In the following table, a "blinking" LED flashes at the rate of once per second; an LED that is "blinking, slow" flashes at the
rate of one second on, five seconds off.
Icon Mode/State
Power • On State
• Idle Mode
• Suspend-to-RAM
• Off State
• Hibernate
(Save-to-Disk)
Charge/ • On State
DC In
• Idle Mode
• Suspend-to-RAM
• Hibernate
(Save-to-Disk)
• Off State
8
LED State
Green, continuous
Green, blinking
Off
Amber
Green
Amber, blinking
Off
Power
Charge/DC In
Battery
HDD Access
Hovering Mode
Figure 1-7 Status Display Icons
Remarks
The system is powered on and ready for use.
The system has suspended and saved active
settings to RAM.
The system has suspended and saved settings
and data to the hard disk drive.
AC adapter and battery are available and system
is charging.
• AC adapter and battery are available and
system is not charging (battery fully
charged).
• AC adapter is available but battery is not
present.
AC adapter and battery are available and waiting
to charge (battery is out of thermal range).
AC adapter is not available.
