Owner's Operation and Instruction Manual
CAUTION!
Please read this entire manual before you install
or use your new room heater. Failure to follow
instructions may result in property damage,
bodily injury, or even death.
Improper Installation Could Void
Your Warranty!
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU
TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
French version is available for download from the U. S. Stove website: http://www.usstove.com/
La version française est disponible pour téléchargement à partir du site U. S. Stove: http://www.usstove.com/
MODEL: AC2000
CONFORMS TO UL STD 1482 and CERTIFIED TO ULC STD S627
WASHINGTON STATE APPROVED
MOBILE HOME APPROVED (U.S. ONLY)
U.S. Environmental Protection Agency
Certified to comply with 2015 particulate emissions standards.
SAVE THESE INSTRUCTIONS
United States Stove Company
227 Industrial Park Road
South Pittsburg, TN 37380
If this heater is not properly installed, a house fire
may result. For your safety, follow the installation
instructions. Never use make-shift compromises
during the installation of this heater. Contact local
building or fire officials about permits, restrictions
and installation requirements in your area.
P.O. Box 151
800-750-2723
SAFETY NOTICE:
852087F-0902G
