- Page 1 User manual Tavara Balance Van Raam BV Aaltenseweg 56 7051 CM Varsseveld Netherlands...
- Page 2 User manual Tavara Balance...
-
Page 3: Table Of Contents
Aaltenseweg 56 7051 CM Varsseveld Netherlands Tel. : +31 (0)315 257370 E-mail : info@vanraam.nl Internet : www.vanraam.nl Conformity Van Raam declares as manufacturer that the Tavara Balance bicycle has been produced in accordance with the 93/42/EEG guidelines. User manual Tavara Balance... -
Page 4: Introduction
Also the local traffic rules should always be complied with. All other use, including damage or physical injuries due to this, are not the manufacturer's responsibility. User manual Tavara Balance... -
Page 5: Safety Measures
Make sure that wide trousers or lose hanging clothing don’t get caught in the • chain, spokes or pedals. Do not use a pressure washer or a steam cleaner for the cleaning of the • bicycle. User manual Tavara Balance... -
Page 6: Delivery Inspection
If an optimal adjustment of the bicycle, as defined in the instructions, is not possible, you can contact your dealer for a fitting solution. The brakes are correctly adjusted as standard and can only be adjusted by the dealer during periodic maintenance. User manual Tavara Balance... - Page 7 Do not pull out the saddle pin further than the marking. The tube will not go into the shank deep enough and will risk coming off. This can lead to MIN INSERT serious injuries. User manual Tavara Balance...
- Page 8 2. Put the handle bars in the desired position and then tighten the screws considerably. 3. Slightly loosen screw (C) with an Allen key, put the handle bars in the correct (horizontal) position and then tighten the screw again. User manual Tavara Balance...
-
Page 9: Accessories
With the socketed screw (A) the crank shortener should be aligned with the crank. 2 assembly points pedal Eccentric crank The bicycle can be fitted with an eccentric crank on the left and/or right side. User manual Tavara Balance... - Page 10 2. Put the charger plug in the wall socket. The red lamp will light up. 3. When the green lamp lights up, the battery is fully charged. 4. Take the plug from the wall socket. 5. Take the plug from the battery. User manual Tavara Balance...
- Page 11 With the red button you shut down the system. If the system is not used, it will automatically shut itself down after a period of time. When walking backwards with the bicycle, always turn off the motor. User manual Tavara Balance...
- Page 12 When charging, first connect the plug to the charging point on the bicycle and then put the plug in the wall socket! When charged, first take the plug from the wall socket and then disconnect the charger from the bicycle! User manual Tavara Balance...
- Page 13 [B]. Then pull the connector from the battery. 2. Undo the lock of the fastening device with the key and open it. 3. Let the battery come ahead and take the battery from the container. User manual Tavara Balance...
- Page 14 • Only use the charger in non-humid indoor spaces. • Below 5 degrees Celsius the charger will not function properly. In that case it is advisable to charge the battery indoors. Extra accessories are available at your dealer. User manual Tavara Balance...
-
Page 15: Before The First Use
You now can change the 3 AA batteries. In case you can not easily reach the screws, slightly loosen screw [A] and tilt the light a quarter turn, so the screws are better accessible. User manual Tavara Balance... -
Page 16: Technical Details
Technical details Length (cm) Frame height (cm) Boarding height (cm) Front wheel 24“ Back wheel 24“ Weight (kg) From 19 Max. load luggage rack (kg) Total max. load (kg) Brakes, front Rim brakes Brakes, back Rim brakes User manual Tavara Balance... -
Page 17: Maintenance And Adjustments To Be Done By Owner
After 200 kilometres or after a period of 2 months the bicycle should be inspected. Check the brakes, the illumination and the spokes. Also check the tyre tread depth. This should be at least 1 mm. Worn out tyres or possible faulty parts should be replaced. User manual Tavara Balance... - Page 18 4. Slightly loosen the screw. Hold the nut at the back tight with a socket wrench to stop the screw from slipping. 5. Shift the tensioning wheel in such a way that the chain hangs loose, as described above. 6. Tighten the screw again. User manual Tavara Balance...
-
Page 19: Repairs And Maintenance To Be Done By Dealer
If you still decide you want to replace components yourself, you are responsible for damage or harm due to incorrectly fitted components. Only use original spare parts, which you can buy at you dealer. If requested the dealer will make the necessary information on repair and maintenance available. User manual Tavara Balance... -
Page 20: Disposal
The guarantee as well as the product liability in general expires if the instructions stated in this manual are not followed. This is also the case if unauthorized maintenance is carried out or if technical changes or additions are made without permission of Van Raam. User manual Tavara Balance... -
Page 21: Frame Number
Frame number The frame number is printed on the sticker. This sticker is located on the frame, see the image below. Example sticker: Frame number Position of sticker: on backside of the saddle tube User manual Tavara Balance...
