MACHINE DESCRIPTION

11
L2
1
2
3
4
5
1
6
2 7
8
9
10
11
3
4
5
1A
6
1B
1C
L1
L2
L3
Hot water knob
Infusion group
Hot water wand
Water collection pan
Filter-holder
Steam wand
Pressure gauge
Machine foot
Steam / Easycream knob
Cup warmer
Tank
Coffee delivery button
dose 1
Continuous coffee
delivery button
Coffee delivery button
dose 2
Tank version light / no
water in tank
Machine heating light
Ghost display
