MACHINE DESCRIPTION

17
16
15
14
KEY
1 Steam knob
2 Hot water dispensing button
3 Control panel
4 Coffee delivery buttons
5 Steam knob
6 Filter-holder
7 Manual steam nozzle
1 2 3
13 12 11
8 Delivery unit
9 Main switch
10 Gravimetric devices
11 2 coffees spout
12 Pressure Gauge
13 Adjustable foot
14 Manual steam nozzle
4
10
15 Data plate
16 Hot water nozzle
17 Electric cup warmer (optional)
5
6
7
8
9
Fig. 1
