3.6 Connecting the 920 Absorber Module to the remaining components
3.6.2

Connecting the Combustion Module (AJ) outlet: absorber solution

1 Absorber solution connection
Connection for the capillary with the yellow
colored sleeve (4-
3 Peltier cooler
For cooling the combustion gases at the
combustion tube's outlet.
18
￭￭￭￭￭￭￭￭
The capillary with the yellow colored sleeve and the thicker capillary are
connected to the CIC T connector in the Combustion Module (AJ).
There are 2 connections on the CIC T connector in the Combustion Mod-
ule (AJ):
Figure 10 Combustion tube – Outlet
9
).
2 T connector CIC (6.7301.210)
T connector on the combustion tube's out-
let. For feeding the absorber solution in and
removing the combustion gases.
4 Combustion gases connector
Connector for the PTFE capillary, 1/8 / 1/16
ID / 1.5 m (6.1803.130) (4-
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
8
).
Combustion-IC-System
