Directed Directechs DS3+ Installation Manual page 13

Module
Conn./Pin Color Description
H2/18 Orange/Black (+) Instant Alarm Input
H2/19 Blue (-) Trunk Input
H2/20 Green (-) Door Input
H2/21 Gray (-) Hood Switch Input [1]
H2/22 Violet/White (AC) Tach Input
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. - Immo. Data Interrupt (vehicle side) BCM under driver dash, green 25 pin plug, pin 2
H3/2 Blue/Red Relay N.O. - No Connection
H3/3 Blue Relay COM - Immo. Data Interrupt (conn. side)
H3/4 White/Brown Relay N.C. - No Connection
H3/5 White Relay COM - No Connection
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red Relay N.O. - (-) Ground [3]
H3/8 Lt. Green Relay COM - (MUX) Clutch Activation Output [3]
H3/9 Lt. Green/White Relay N.C. - No Connection
H3/10 Black (-) Ground
H3/11 White Relay COM - No Connection
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black (+) 12 Volt Input
H4/3 Pink/Black Flex Relay (pin 87a)
H4/4 Pink/White (+) Flex Relay Output
H4/5 Red (+) 12 Volt Input
H4/6 Green Starter Disable (conn. side)
H4/7 Violet (+) Starter Output (vehicle side)
H4/8 Orange (+) Accessory Output
H4/9 Red/White (+) 12 Volt Input
H4/10 Pink (+) Ignition Input/Output
13 933.GM9 2.42.195.3 2015 Cadillac CTS Sedan (Smart Key)
©2021 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
Connects To
Wire Location
No Connection
BCM under driver dash, green 25 pin plug, pin 2
No Connection
No Connection
BCM under driver dash, blue 27 pin plug, pin 4
Must use a 180 ohm resistor.
Not Applicable
No Connection
No Connection
BCM under driver dash, blue 27 pin plug, pin 4
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
(+/-) Wire Color Connection
Data Green/Violet Remote Start
Only
Data Green/Violet Remote Start
Only
+ Red/Gray (30A) Mandatory
(chassis ground) Remote Start
Only
Remote Start
Only
(chassis ground) Mandatory
+ Red/Gray (30A) Mandatory
(+/-) Wire Color Connection
