Soundoff Signal ETSS100NBKTH Quick Start Manual

2017 CHEVROLET TAHOE SPEAKER BRACKET
ETSS100NBKTH (for 2017-2020 model years only)
FIG. 1
Please see next page for Technical Specifications
WARNING
•HIGH CURRENT interconnects must be properly terminated. Poor crimp quality can cause heat build-up and fire. Follow crimp connector
manufacturer instructions.
•DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to vehicle Owner's Manual for deployment zones.
•Do NOT use system to disconnect headlights, brake lights or other safety equipment.
•Unit may become hot to touch during normal operation.
•Failure to properly install connectors, fuses or wiring may cause vehicle failure or fire.
•Installation must only be performed by trained technician. Installer must determine vehicle wiring configuration and proper integration of system.
•Use proper wire gauge. All power wires connecting to positive (+) or negative (-) battery terminal or local chassis ground (-) must be sized to
supply at least 125% of max. current and properly fused at power source.
•Install protective grommets when routing wire through firewall or metal.
1.800.338.7337 / www.soundoffsignal.com
1
FIG. 2
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundoffsignal.com.
NOTICE:
Improper use or installation may void warranty coverage.
E N H A N C I N G S A F E T Y T H R O U G H I N N O VAT I O N
INSTALLATION:
1. Front bumper cover assembly must be removed
to install speaker bracket. Assembly should
be removed as one piece and not individually.
Consult a local Chevrolet service center for best
disassembly method. Keep all hardware.
2. Assemble bracket:
- If using one speaker, choose location and
use support bracket. (See Figure 1.)
- If using two speakers, support bracket is
not used (See Figure 2.)
!
WARNING
Sirens produce loud sounds that
may damage hearing
I
Roll up windows
I
Wear hearing protection
I
Use only for emergency response
I
Avoid exposure to siren sound
outside of vehicle
ETSS100NBKTH 0120
