Soundoff Signal ETSS100CBKDC15 Quick Start Manual

CHARGER BUMPER SPEAKER BRACKET
ETSS100CBKDC15 (for 2015 - 2021 model years)

WARNING

•HIGH CURRENT interconnects must be properly terminated. Poor crimp quality can cause heat
build-up and fire. Follow crimp connector manufacturer instructions.
•DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to vehicle
Owner's Manual for deployment zones.
•Do NOT use system to disconnect headlights, brake lights or other safety equipment.
•Unit may become hot to touch during normal operation.
•Failure to properly install connectors, fuses or wiring may cause vehicle failure or fire.
•Installation must only be performed by trained technician. Installer must determine vehicle wiring
configuration and proper integration of system.
•Use proper wire gauge. All power wires connecting to positive (+) or negative (-) battery terminal
or local chassis ground (-) must be sized to supply at least 125% of max. current and properly fused at
power source.
•Install protective grommets when routing wire through firewall or metal.
1.800.338.7337 / www.soundoffsignal.com
1
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to techservices@soundoffsignal.com.
TO AVOID DAMAGE TO SPEAKER USE THE SUPPLIED PLASTIC WASHERS ON
BOTH SIDES OF METAL BRACKET. FOLLOW INSTRUCTIONS ON NEXT PAGE.
ASSEMBLY SHOWN IS REPRESENTATIVE ONLY. EACH SPEAKER
IS SLIGHTLY DIFFERENT AND INSTALLER IS RESPONSIBLE FOR
SECURE MOUNTING IN BRACKET.
NOTICE:
Improper use or installation may void warranty coverage.
E N H A N C I N G S A F E T Y T H R O U G H I N N O VAT I O N
BRACKET COMPATIBLE WITH SPEAKERS:
- 100C
- 100N
- 100J
!
WARNING
Sirens produce loud sounds that
may damage hearing
I
Roll up windows
I
Wear hearing protection
I
Use only for emergency response
I
Avoid exposure to siren sound
outside of vehicle

IMPORTANT

TECHNICAL SPECIFICATIONS
Material: Steel with powder coated black
finish
Dimensions 11"H x 7.3"W x 4.5"D
(bracket only):
ETSS100CBKDC15 0221
