- Page 1 Instruction Guide 40669SH Kargo Master Rancho Cordova, CA 95742 800-343-7486 CustomerService@KargoMaster.com 20210203R2 DATE: ________________...
-
Page 2: Table Of Contents
Step 8 – Installing Partition to Floor ........................8 Step 9 – Install Partition to B-pillar ........................8 Before You Begin READ ALL INSTRUCTIONS prior to installing any Kargo Master product. Be sure to have 40660 (Tall Partion) assembled and ready to be installed. ... -
Page 3: Parts List
Instructions – 40669SH Parts List Hardware For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 2... -
Page 4: Hardware (Continued)
Instructions – 40669SH Hardware (Continued) Step 1 – Attach Top Panel Using six 1/4” x 5/8” flanged bolts and 1/4” flanged locknuts, bolt top panel to partition (40660). Snug tighten but allow for movement. For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) -
Page 5: Step 2 - Attach Driver Side Corner Panel
Instructions – 40669SH Step 2 – Attach Driver Side Corner Panel NOTE: The corner brackets are side specific. Verify the correct bracket position prior to installing. Using four 1/4” x 5/8” flanged bolts and 1/4” flanged lock nuts, bolt DS corner panel to partition and top panel. -
Page 6: Step 4 - Attach Side Wings
Instructions – 40669SH Step 4 – Attach Side Wings Using five 1/4” x 5/8” flanged bolts and 1/4” flanged lock nuts, bolt PS side wing to partition. Snug tighten but allow movement. Using five 1/4” x 5/8” flanged bolts and 1/4”... -
Page 7: Step 5 - Installing Plus Nuts
Instructions – 40669SH Step 5 – Installing Plus Nuts NOTE: Additional lock nuts have been provided for alternate installation of the bolts through the floor. Press the assembled partition so that wings are firmly against each B-pillar and so that the top wing is squarely against and across the roof support of the van. -
Page 8: Step 7 - Installing Partition To Roof Cross Brace
Instructions – 40669SH At each location marked, drill a hole using a 25/64” bit. A 3/8” drill bit can be used, although it may be necessary to tap in the plus nuts. Screw 1/4” x 2-1/4” hex head bolt through 1/4” flat washer and plus nut installation tool, and then into plus nut. -
Page 9: Step 8 - Installing Partition To Floor
Instructions – 40669SH Step 7 – Installing Partition to Floor Using four 1/4" x 1-1/4” hex head bolts, 1/4" lock washers, 1/4" flat washers, and 3/8” nylon spacers, bolt partition to installed plus nuts. Spacers are optional, but be sure to place under partition and bolt through 3/8”...
