7 ． Troubleshooting
This section provides a few useful tips to quickly get GSPI-Q3700-LLVA running with success. This section
will primarily focus on system integration issues, in terms of BIOS setting, and OS diagnostics.
◆Hardware Quick Installation
ATX Power Setting
Unlike other Single board computer, GSPI-Q3700-LLVA supports ATX only. Therefore, there is no other
setting that needs to be set up. However, there are only two connectors that must be connected— J15 (ATX 8
Pin Connector (For CPU Power)) on the GSPI-Q3700-LLVA board & 20 pins ATX Power Connector on the
carrier board
GSPI-Q3700-LLVA User's Manual
